WEIDMULLER 2108720000 Spring Connection Terminal Block
The Weidmuller A-series ZQV 2.5N/6 RD terminal block features PUSH IN technology, minimizing wiring time and ensuring high conductor pull-out forces. This terminal block is ideal for applications requiring efficient and reliable connections. It's constructed from Wemid material with a V-0 flammability rating and offers explosion-tested versions for demanding environments. Note that breaking out more than 60% of contact elements reduces stability and temperature resistance, and cross connectors reduce rated voltage.
WEIDMULLER 2108720000 Spring Connection Terminal Block Specifications:
- Width: 28.3 mm
- Height: 24.7 mm
- Depth: 2.8 mm
- Net weight: 3.455 g
- Width(inches): 1.114 inch
- Height(inches): 0.972 inch
- Depth(inches): 0.11 inch
- Storage temperature max: 55 °C
- Storage temperature min: -25 °C
- Material: Wemid
- UL 94 flammability rating: V-0
- Colour: red
- Explosion-tested version: Yes
- Type of mounting: Direct mounting
- Type of fixing: Plugged
- Pitch in mm (P): 5.1 mm
- Rated current: 24 A
- ETIM 6.0: EC000489
- eClass 9.0: 27-14-11-40
- eClass 10.0: 27-14-11-40
- ETIM 7.0: EC000489
- eClass 9.1: 27-14-11-40
- Product information: Due to stability and temperature reasons It is only possible to break out 60% of contact elements The usage of cross connectors reduces the rated voltage to 400VThe voltage reduced to 25V if cut cross connection with blank cut edges are used
