WEIDMULLER 2466920000 Power Supply Module
The PRO TOP1 960W 48V 20A power supply provides reliable, efficient switching operation suitable for industrial applications. It features high power reserves, overvoltage and temperature protection, and long service life, ensuring stable performance in challenging environments. Equipped with DCL technology, it offers an outstanding dynamic range for circuit breaker triggering and motor starts. Its robust metal housing allows installation on DIN rails with sufficient clearance for airflow. The device meets international standards for EMC, safety, and environmental compliance, making it a versatile choice for automation and control systems.
WEIDMULLER 2466920000 Power Supply Module Specifications:
- Dimensions: Width 124mm (4.882 inches), Height 130mm (5.118 inches), Depth 125mm (4.921 inches)
- Net weight: 3.382 kg
- Input voltage range: 85-277 VAC / 80-410 VDC
- AC frequency: 45-65 Hz
- Output power: 960 W, 48 V, 20 A
- Output voltage: 45-56 V, nominal 48 V ±1%
- Efficiency: >94%
- Temperature range: -25°C to 70°C with derating above 60°C
- Surge protection: Varistor, peak load reserve 150% (5 sec), 400% (15 ms)
- Protection: Short-circuit, inverse voltage, overload, surge, and overload
- Environmental: Humidity 5-95%, no condensation; IP20 protection
- EMC compliance: EN55032 Class B; vibration resistance IEC 60068-2-6 2.3g
- Safety: IEC 60950, EN60204, SELV/PELV safety classification
- Mounting: Horizontal on DIN rail, minimal clearance for airflow
- Certifications: RoHS, Conform
Buy the Buy Weidmueller Power Supply Part Number 2466920000 Online
Secure your industrial automation needs with the Weidmueller PRO TOP1 960W power supply. Designed for high efficiency, durability, and safety, this 48V, 20A switch-mode unit ensures stable voltage delivery under demanding conditions. Its robust metal housing mounts easily on DIN rails, with ample clearance for airflow to prevent overheating. The device features comprehensive protection, including short-circuit, overload, and surge protection, ensuring long service life. Perfect for control panels, motor drives, and automation systems, order online today for fast delivery and reliable operation.
Buy Weidmueller PRO TOP1 960W 48V 20A power supply now and experience unmatched reliability and performance in industrial automation.
Frequently Asked Questions
Where can I buy WEIDMULLER 2466920000?
You can click on the BUY or RFQ button to purchase 2466920000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2466920000?
You can download the 2466920000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2466920000?
WEIDMULLER
