WEIDMULLER 8951120000 Solid-State Relay
The TERMOPTO solid-state relay offers reliable switching for AC loads up to 230 VAC at 0.1A current, ideal for automation and control applications. Featuring a compact 6.1 mm width, it has screw connections, integrated input protection circuits including varistors, and a pluggable cross-connection design for easy installation. Suitable for environments requiring silent operation with a fast response time, the relay incorporates a zero-cross switching Triac contact, ensuring minimal electrical noise. Its robust enclosure and UL 94 V-0 flammability rating ensure safety and durability in industrial settings. Operating temperatures range from -20°C to 60°C, accommodating various industrial applications with high reliability.
WEIDMULLER 8951120000 Solid-State Relay Specifications:
- Width: 6.1 mm (0.24 inch)
- Height: 74.4 mm (2.929 inch)
- Depth: 55 mm (2.165 inch)
- Net weight: 20.59 g
- Operating temperature: -20°C to 60°C
- Maximum storage temperature: 80°C
- Control voltage: 24 V DC ±20%
- Rated control current: 3.6 mA DC
- Power rating: <80 mW
- Control voltage range: 24 V DC / 230 V AC
- Rated switching voltage: 24...230 VAC
- Rated load current: 100 mA
- Switching delay: <10 ms (on), <12 ms (off)
- Voltage drop: <18 V at max load
- Insulation voltage: 300 V
- Dielectric strength: 1.2 kV for 1 min
- Protection degree: IP20
- Connection method: Screw connection, stripping length 9mm
- Wire cross-section: AWG 20 min, AWG 12 max, flexible and stranded options
- Flammability rating: UL 94 V-0
- Compliance: DIN EN 50178, IEC, UL
- Safety: Surge voltage category for load side >3mm clearance and creepage distances
Buy the Weidmiiller Series TOS Solid-State Relay: 8951120000
Purchase the Weidmiiller Series TOS solid-state relay now for safe and dependable switching of AC loads up to 230 VAC at 0.1A. Its compact size, screw connection, integrated input protection circuits, and robust enclosure make it ideal for industrial automation, control systems, and equipment. The relay features zero-cross switching for reduced electrical noise, fast response times, and complies with safety standards. Easy to install and maintain, it ensures high reliability in demanding environments. Get yours online today and enhance your control system's performance with this durable and efficient relay designed for industrial success.
Order your Weidmiiller Series TOS solid-state relay today and enjoy reliable performance with compact design for industrial control applications.
