Weidmuller BLZ5086 female connector
The female plugin connector with a 5.08 mm pitch and straight outlet direction is designed for reliable wire connections using a clamping yoke. Suitable for PCB applications, it features 6 poles, a maximum clamping range of 3.31 mm, and a rated voltage of 400 V/ IEC and 300 V/ UL. The connector is made of orange PBT with copper alloy contacts, tin-plated for durability. It supports a wire cross-section from AWG 26 to AWG 12, with a maximum of 2.5 mm cross-section. Certified for safety and UL, CSA, and IEC standards, it offers easy wiring, secure connection, and high-quality manufacturing.
Weidmuller BLZ5086 female connector Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 6
- Rated voltage: 400 V IEC / 300 V UL
- Rated current: 16A at 40°C IEC / 15A UL
- Clamping range: 0.13 mm to 3.31 mm
- Wire cross-section: AWG 26 to AWG 12
- Material: PBT insulating, copper alloy contacts, tin-plated
- Temperature range: -50°C to 100°C operating, -25°C to 100°C installation
- Safety: IP20, touch-safe protection, UL 94 V0 flammability
- Screw size: M2.5, tightening torque: 0.4-0.5 Nm
- Push-in connection, 25 plug cycles, withdrawal force: 8N per pole
- Certification: UL, CSA, IEC standards, RoHS compliant
- Dimensions: Length approximately 25.4 mm, net weight 9.26 g
- Packaging: Box
Buy the Weidmuller BLZ5086 – Reliable PCB Female Connector for Industrial Applications
Enhance your industrial wiring with the highly reliable female connector featuring a 5.08 mm pitch and 6 poles, suitable for PCB applications. Constructed with durable PBT insulation and copper alloy contacts, it ensures secure connections, safety, and long-term performance. With a clamping range of 0.13 to 3.31 mm, it supports wire cross-sections from AWG 26 to AWG 12. Certified for IEC, UL, and CSA standards, this connector is ideal for demanding industrial environments. Order online today for quick, secure, and dependable wiring solutions.
Buy Weidmuller BLZ5086 now and experience unmatched reliability and performance in PCB wiring and industrial connections.
Frequently Asked Questions
Where can I buy Weidmuller BLZ5086?
You can click on the BUY or RFQ button to purchase BLZ5086 from an authorized Weidmuller distributor.
How do I troubleshoot issues or seek technical support for part BLZ5086?
You can download the BLZ5086 datasheet or visit the Weidmuller website for support.
Who is the manufacturer of BLZ5086?
Weidmuller
