XP POWER ECL15US24E Industrial Power Supply
The ECL15US24 power supply offers a compact, encapsulated design ideal for industrial applications requiring high efficiency and reliable performance. It features adjustable output voltage, overvoltage and overload protection, and performs efficiently across a wide input voltage range of 85-264 VAC. Its ultra-compact size and multiple mounting options—including PCB, chassis, and encapsulated versions—make it versatile for various enclosures. With a peak load capacity of 130% for <30 seconds and a 3-year warranty, it ensures durability and consistent power supply in demanding environments.
XP POWER ECL15US24E Industrial Power Supply Specifications:
- Input Voltage: 85-264 VAC (120-370 VDC)
- Frequency Range: 47-63 Hz
- No Load Power Consumption: <0.3 W
- Output Power: 15 W
- Output Voltage: 24 VDC (±5%)
- Load Regulation: <3% across 10-100% load for one fixed output, <10% for others
- Peak Load Capability: 130% lasting <30 s with a maximum duty cycle of 10%
- Efficiency: 80-83% depending on model
- Protection: Overvoltage, Overload, Short Circuit, and Hiccup Mode
- Isolation: 3000 VAC input-to-output
- Operating Temperature: -20°C to +70°C, derating from 100% at 50°C to 50% at 70°C
- Dimensions: 2.96 x 1.50 x 0.70 inches (open frame PCB mount)
- Certifications: UL, EN55032, EN61000-3-2, EN61000-4-2/3/4/5/6
- Vibration: 2g, 10 Hz to 500 Hz for 10 mins/cycle
- MTBF: >400,000 hours (at 25°C)
Buy the Buy Power Supply Part Number ECL15US24 Online
Enhance your automation or control systems with the reliable and high-performance Power Supply ECL15US24. Designed for versatility and durability, it features adjustable output voltage, multiple protection features, and wide input compatibility. Its compact, encapsulated design allows flexible mounting options—including PCB, chassis, and encapsulated versions—making it perfect for various enclosures and environments. With a peak load capacity of 130% for less than 30 seconds and a 3-year warranty, this power supply ensures continuous operation, energy efficiency, and peace of mind for industrial, automation, and electronic applications.
Get Power Supply ECL15US24 today—built for precision, high efficiency, and long-lasting durability in demanding environments.
Frequently Asked Questions
Where can I buy XP POWER ECL15US24E?
You can click on the BUY or RFQ button to purchase ECL15US24E from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ECL15US24E?
You can download the ECL15US24E datasheet or visit the XP POWER website for support.
Who is the manufacturer of ECL15US24E?
XP POWER
