XP POWER IE1205D Industrial Power Module
The IE1205D is a highly efficient, compact 1-watt power supply designed for reliable operation in industrial and electronic applications. Featuring a universal input voltage range, low ripple and noise, and high isolation voltage, it ensures stable power delivery. Its small SIP or DIP package sizes make it ideal for space-constrained environments. The power supply operates from -40°C to +85°C, with optional 3.0kV DC isolation, and boasts a long MTBF of over 1.1 million hours, meeting safety and environmental standards with UL94V-0 casing and convection cooling.
XP POWER IE1205D Industrial Power Module Specifications:
- Input Voltage Range: Unspecified
- Input Reverse Voltage: Unspecified
- Ripple Current: 20 mA pk-pk at 5Hz to 20 MHz
- Ripple & Noise: 100 mV pk-pk max, 20 MHz bandwidth
- Efficiency: 23%
- Isolation Voltage: 1000 VDC minimum, optional 3000 VDC
- Isolation Resistance: Unspecified
- Isolation Capacitance: 60 pF typical
- Switching Frequency: 40-150 KHz variable
- MTBF: >1.1 million hours at 25°C, GB
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +125°C
- Case Material: Non-conductive UL94V-0 rated plastic
- Pin Material: SIP alloy, DIP brass with solder coating
- Dimensions: Small package sizes, specifics in inches and mm
- Cooling: Convection-cooled
- Safety Compliance: CE & UKCA, meets applicable directives
- Maximum Capacitive Load: 220 UF
- Temperature Coefficient: 0.02%/°C
Buy the Power Supply Series IE1205D 1 Watt: IE1205D
Enhance your electronic or industrial setup with the IE1205D power supply, offering high efficiency, wide temperature operation, and reliable isolation. Its compact size makes it perfect for space-saving designs, while its long MTBF ensures dependable performance. Easily integrate in various environments with IEC safety standards and high-temperature endurance. Designed for those demanding robustness and consistency, this power module simplifies your power management needs. Order online today and ensure stable, safe power delivery for your critical systems.
Buy IE1205D power supply now and experience unmatched reliability and performance in your embedded and industrial systems.
Frequently Asked Questions
Where can I buy XP POWER IE1205D?
You can click on the BUY or RFQ button to purchase IE1205D from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IE1205D?
You can download the IE1205D datasheet or visit the XP POWER website for support.
Who is the manufacturer of IE1205D?
XP POWER
