XP POWER ITP0324S12 DC-DC Power Module
The ITP series is a compact, 3W DC-DC power module offering a cost-effective solution with a wide input voltage range and regulated outputs. It provides regulated single and dual output voltages from 3.3V to 15V DC, with a wide 4:1 input voltage range, including options from 4.5V to 18V, 9V to 36V, and 18V to 75V DC. The module features an ultra-compact SIP6 package, with 1.6kV DC input/output isolation, high efficiency, and compliance with EN55032 standards. It includes short-circuit protection and remote on/off control for single-output versions. Operating temperature range is from -40°C to +75°C, allowing full power operation up to +70°C.
XP POWER ITP0324S12 DC-DC Power Module Specifications:
- Output Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75V DC
- Input Currents: up to 55 mA at maximum load
- Output Voltage Options: 3.3V, 5V, 12V, 15V (single and dual outputs)
- Output Current: up to 700 mA depending on model
- Efficiency: up to 83%
- Isolation Voltage: 1.6 kVDC
- Operating Temperature Range: -40°C to +75°C
- Package Type: SIP6 ultra-compact
- Protection: Short-circuit and overload protection
- Remote On/Off: Available for single output versions
- Standards: EN55032 compliance
- Dimensions: 17.0 x 10.1 x 11.7 mm
- Warranty: 3 years
Buy the Buy XP Power DC-DC Converter Part Number ITP0324S12 Online
Purchase the XP Power ITP0324S12 DC-DC converter online today and enjoy reliable power conversion in a compact package. With a wide input voltage range from 4.5V to 75V DC, this 3W module offers regulated single and dual outputs with efficiencies up to 83%. It features an ultra-compact SIP6 package, 1.6kVDC isolation, and operates from -40°C to +75°C. Ideal for industrial, automation, and embedded systems, it includes short-circuit protection and remote on/off control, ensuring safety and performance for critical applications.
Buy XP Power ITP0324S12 now and experience unmatched reliability and high efficiency in a compact, cost-effective DC-DC power solution.
Frequently Asked Questions
Where can I buy XP POWER ITP0324S12?
You can click on the BUY or RFQ button to purchase ITP0324S12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0324S12?
You can download the ITP0324S12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0324S12?
XP POWER
