3M N25166002RB Low Profile Connector

This is a 0.100-inch low-profile, surface-mount technology (SMT) straight connector available in both straight and right-angle through-hole configurations. It belongs to the 2500 Series, designed for reliable electronic connections in compact assemblies. Features include polarization to prevent mis-insertion, optional retainer clips for vibration resistance, and high-temperature insulators for lead-free soldering. Made from glass-filled polyester or PCT, with copper alloy contacts, gold or tin-lead plating, rated for up to 5A, and operating from -55°C to +105°C, suitable for dense, high-reliability electronic applications.

Authorized Distributors
Source:DigiKey
Part No:N2516-6002-RB
Stock:0
Inv Date:05-29-2026
Price: Unit price: $2.11
Buy/RFQ:
Part No:N2516-6002RB
Stock:0
Inv Date:05-30-2026
Price: Unit price: $1.9
Buy/RFQ:
Part No:N2516-6002-RB
Stock:0
Inv Date:05-29-2026
Price: Unit price: $1.61
Buy/RFQ:
Part No:N2516-6002-RB
Stock:969
Inv Date:05-29-2026
Price: Unit price: $1.99
Buy/RFQ:
Part No:N2516-6002-RB
Stock:1274
Inv Date:05-29-2026
Price: Unit price: $1.4017
Buy/RFQ:
Part No:N2516-6002-RB
Stock:7645
Inv Date:05-29-2026
Price: Unit price: $1.4017
Buy/RFQ:
Part No:N2516-6002-RB
Stock:969
Inv Date:05-29-2026
Price: Unit price: $1.99
Buy/RFQ:
Source:Arrow EU
Part No:N2516-6002-RB
Stock:6838
Inv Date:05-30-2026
Price: N/A
Buy/RFQ:

3M N25166002RB Low Profile Connector Specifications:

  • Material: Glass-filled Polyester (PBT) or PCT (High Temp Option)
  • Flammability: UL 94V-0
  • Color: Gray or Black
  • Contact Material: Copper Alloy
  • Plating: Gold (selective), Tin-Lead or Matte Tin
  • Current Rating: 5.00 A, 3.00 A, 1.75 A depending on contact configuration
  • Insulation Resistance: >1 x 10^9 Ω at 500 V
  • Withstanding Voltage: 1000 V at sea level
  • Temperature Rating: -55°C to +105°C
  • Process Rating: PCT high temp 260°C, PBT max 191°C
  • Moisture Sensitivity Level: 1
  • Dimensions: 0.100” x 0.100”, suitable for .062” or .094-.125” thick boards
  • UL File No.: E68080

Buy the 3M N25166002RB – Reliable Connector for Industrial Applications

Enhance your electronic projects with the robust and space-saving 3M Low Profile Connector. Designed for surface mount and through-hole applications, it offers polarized features, optional locking retainers, and high-temperature insulators for no-lead soldering. Crafted with durable materials like glass-filled polyester or PCT and plated with gold or tin for excellent conductivity and corrosion resistance, this connector supports up to 5A current and operates reliably from -55°C to +105°C. Perfect for compact, high-reliability electronic systems, ensuring secure and efficient connections every time.

Buy 3M N25166002RB low-profile connector now and experience unmatched reliability and performance in dense electronic assemblies.
