Handy panel current meter allows placement of a current meter anywhere. With a shunt already on board this meter hooks up very easily. Requires a DC voltage to run, and has two thick wires to measure current draw.




3 digit, 7-segment display

Measurement range: 0.01~9.99A

15~25mA draw

14cm long wires, 26 AWG for power wires, 20 AWG for current wires

0.01 ohm shunt

Accuracy is about 4%, better at currents over 2A

Refresh rate: about 2 Hz

Red LCD display

Reverse polarity protectedDimensions:

Dimensions: 48mm x29mm x 21mm





Digit size: 0.56" high, red LEDs
