AMPHENOL INDUSTRIAL MB01TA0910SN574 Micro-B Connector
Amphenol's Micro-B Series Connectors are designed for modern electrical equipment requiring a compact, lightweight, high-density interface with excellent EMI shielding and high reliability. These rugged connectors feature a durable aluminum shell with a triple bayonet coupling mechanism (1/4 turn mating) and stamped and formed contacts, ensuring high mating cycles and effective shell-to-shell electrical bonding for EMI. Suitable for automotive, automation, instrumentation, robotics, security, telecommunications, and measurement applications, they offer versatile mounting options, cost-effective performance, and robust construction for challenging environments.
AMPHENOL INDUSTRIAL MB01TA0910SN574 Micro-B Connector Specifications:
- Shell Material: Aluminum
- Contact Material: Copper Alloy, Tin/Gold Plated
- Mating Cycles: 500 Cycles
- Operating Temperature Range: -40°C to 125°C
- Ingress Protection: IP67 when mated with backshell or cable gland
- Contact Size: 22D
- Current Rating: 3A
- Test Voltage: AC 500V RMS
- Insulation Resistance: 1000 MΩ at 500V
- Vibration Resistance: Tested per IEC-364-28D
- Salt Spray Resistance: Up to 500 hours with Gray ZnNi coating
- Mechanical: High shock and vibration resistance
- Mounting Options: In-line, 2-hole flange
- Key/Keyway: 5 Key/keyway types
- Sealing: IP54 with heat shrink, IP67 with cable gland backshell
- Certifications: RoHS Compliant, UL certification in process
Buy the Amphenol MB01TA0910SN574 – Reliable Micro-B Connectors for Industrial Applications
Enhance your industrial and automation systems with Amphenol Micro-B Connector series, offering a compact, lightweight design with high durability, high mating cycles, and excellent EMI shielding. Made from a robust aluminum shell with a triple bayonet coupling, these connectors ensure quick, reliable connections in harsh environments. Suitable for automotive, robotics, security, and telecommunication applications, they feature versatile mounting options and IP67 protection when combined with cable glands or heat shrink. Buy online today for superior electrical performance and cost-effective durability.
Order your Amphenol Series MB01TA0910SN574 today and give your projects the dependable quality they deserve in demanding industrial environments.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL MB01TA0910SN574?
You can click on the BUY or RFQ button to purchase MB01TA0910SN574 from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part MB01TA0910SN574?
You can download the MB01TA0910SN574 datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of MB01TA0910SN574?
AMPHENOL INDUSTRIAL
