AMPHENOL LTD 62GB5851832P Miniature Bayonet Connector
The 62GB series connectors are miniature bayonet lock connectors compliant with MIL-C-26482E, designed for reliable electrical connections in demanding environments. Available in brass or stainless steel shells with corrosion-resistant finishes, these connectors feature gold-plated contacts for soldered connections. They support a range of insert configurations for various current and voltage ratings, including hermetic sealed versions with glass dielectric. The connectors provide positive shell-to-shell keying to prevent mis-mating and come with multiple assembly options for cable, box, and flange mounting. They are widely used in military, aerospace, and industrial applications requiring robust, sealed, and precise interconnections.
AMPHENOL LTD 62GB5851832P Miniature Bayonet Connector Specifications:
- Shell Material: Brass or stainless steel
- Finish: Zinc cobalt olive drab (standard), cadmium plate (special order), other finishes available
- Operating Temperature Range: -55°C to 125°C
- Insert Types: Polychloroprene rubber, hermetic glass sealed dielectric
- Contact Sizes: 8 to 24 contacts, with current ratings up to 45 A per contact
- Voltage Ratings: 700V, 1200V DC working, with peak proof voltages up to 3000V
- Sealing: Grommet, grommet nut, and strain relief options for environmental sealing
- Keying: Positive shell-to-shell keying with standard and alternate orientations (B, C, E, F)
- Assembly: Cable, box, flange, and single hole mounting styles available
- Certifications: MIL-C-26482E, UL Listed, CSA Certified
- Finish: Zinc cobalt olive drab, cadmium plate, electroless nickel, black anodise, gold plating
Buy the Buy Amphenol 62GB Series Connector Part Number 62GB5851832P Online
Purchase the Amphenol 62GB Series miniature bayonet connectors online today. Designed for durability and reliability in harsh environments, these MIL-C-26482 compliant connectors come with corrosion-resistant finishes, multiple mounting options, and high current and voltage ratings. Perfect for military, aerospace, and industrial applications, they feature positive keying to prevent mis-mating, hermetic sealing options, and gold-plated contacts for soldered connections. Secure your supply chain and benefit from fast delivery and expert support by ordering now.
Order your Amphenol 62GB Series connector 62GB5851832P today and ensure reliable, sealed connections for demanding military and industrial projects.
Frequently Asked Questions
Where can I buy AMPHENOL LTD 62GB5851832P?
You can click on the BUY or RFQ button to purchase 62GB5851832P from an authorized AMPHENOL LTD distributor.
How do I troubleshoot issues or seek technical support for part 62GB5851832P?
You can download the 62GB5851832P datasheet or visit the AMPHENOL LTD website for support.
Who is the manufacturer of 62GB5851832P?
AMPHENOL LTD
