Advantech Automation ADAM4024B1E 4-channel Analog Output Module
The ADAM-4024-B1E is a 4-channel analog output module equipped with Modbus communication protocol. It features four digital inputs suitable for integration tasks such as emergency latch outputs or user default triggers. The device employs optical isolators to prevent ground loop issues and safeguard against power surges. Supporting ASCII commands and Modbus/RTU protocol, this module is ideal for automation and industrial process control, offering reliable connectivity and accurate analog output for complex control systems in manufacturing and automation environments.
Advantech Automation ADAM4024B1E 4-channel Analog Output Module Specifications:
- Connectors: 2x plug-in terminal blocks (#14 ~ 28 AWG)
- Power Consumption: 3W@ 24 Voc
- Watchdog Timer System: 1.6 seconds
- Supported Protocols: ASCII command and Modbus/RTU
- Channels: 4 channel analog output
- Output Impedance: 0.5Ω
- Output Range: 0-20 mA, 4-20 mA, 0-10 V
- Output Type: mA, V
- Accuracy: ±0.1% of FSR for current output, ±0.1% of FSR for voltage output
- Input Types: mA, V, Thermistor, RTD
- Temperature Ranges: Thermistor 0~100°C (3K), 0~100°C (10K); RTD Pt 100/1000
- Resolution: 12-bit
- Isolation Voltage: 3,000 VDC
- Programmable Output Slope: 0.125 ~ 128 mA/sec, 0.0625 ~ 64 V/sec
- Readback Accuracy: ±1% of FSR
- Digital Inputs: 2 channels, dry contact, logic level 0: close to GND, 1: 10 ~ 30 VAC
- Digital Outputs: Open collector, to 30 V, 30 mA max.
- Operating Temperature: -10~70°C
- Storage Temperature: -25~85°C
- Environmental Humidity: 5~95% RH
- Power Input: 10 ~ 30 VDC
- Dimensions: Compatible with industrial control systems
Buy the Buy Automation Components ADAM 4024 Part Number ADAM4024B1E Online
Purchase the ADAM 4024B1E online today to enhance your automation system with reliable 4-channel analog outputs, digital inputs, and robust digital communication support. Designed for industrial control environments, this module features optical isolation to prevent ground loop issues and safeguards against power surges. Its compatibility with ASCII commands and Modbus/RTU protocol ensures seamless integration into existing control systems. Whether for manufacturing automation or process control, this product offers high accuracy, flexible output ranges, and durable performance, all available for quick online purchase.
Buy ADAM 4024B1E now and experience unmatched reliability and performance with robust analog output capabilities and industrial-grade isolation.
