Advantech Automation ICR3201W Industrial IoT Gateway
The ICR-3201W industrial IoT LAN router and gateway offers robust connectivity with dual Ethernet ports, serial interfaces RS232 and RS485, and optional Wi-Fi 802.11ac with MU-MIMO, plus Bluetooth v5.1. Designed for harsh environments, it operates from -40°C to +75°C with a durable metal cover supporting DIN and wall mounting. Featuring a powerful Cortex A8 CPU at 1GHz, 512MB RAM, 4GB eMMC flash, and advanced security protocols including VPN tunnels and firewalls, this device supports industrial protocols and open Linux development for scalable IoT solutions. Ideal for traffic, meters, and industrial control applications.
Advantech Automation ICR3201W Industrial IoT Gateway Specifications:
- Network and Routing: DHCP Server, NAT/PAT, VLAN, QoS, VPN tunnels, Firewall, Dual Stack IPv4/IPv6, BGP, OSPF, Dynamic DNS, NTP, SNMP v1/ v2c/ v3
- Security: HTTPS, SSH, VPN (OpenVPN, IPsec, L2TP, PPTP, GRE), Firewall with IP and MAC filtering, DMZ
- Interfaces: 2x Ethernet 10/100 Mbps, 1x RS232, 1x RS485, USB, optional Wi-Fi 802.11ac MU-MIMO, Bluetooth v5.1, digital I/O
- Processor: Cortex A8 1GHz, 512MB RAM, 4GB eMMC Flash for customer applications
- Power: 9-36V DC, low power consumption with Wi-Fi active 2.5/4W, idle 2.5W, peak 11W, sleep mode 10mW
- Environmental: Operating temperature -40°C to +75°C, humidity 0-95% non-condensing, rugged metal enclosure with DIN and wall mounting
- Wireless: Dual-band Wi-Fi 2.4GHz/5.8GHz, support for 802.11a/b/g/n/ac, MU-MIMO, WEP/WPA/WPA2 security, Bluetooth 5.1
- Size: 31.2 x 94 x 129 mm, weight approx. 477g, includes mounting options, antenna connectors R-SMA
- Certifications: EN 301 893, FCC Part 15, CE, RoHS, REACH, MIL-STD-810G compliance
- Development & Management: Open Linux platform, Python, C/C++, Node-RED, WebAccess/DMP, remote diagnostics, firmware updates
Buy the Buy Advantech ICR-3201W Industrial IoT Router Gateway Part Number ICR3201W Online
Purchase the Advantech ICR-3201W industrial IoT router and gateway online to unlock reliable connectivity with dual Ethernet, serial ports, Wi-Fi, Bluetooth, and advanced security. Its rugged metal enclosure ensures durability in harsh environments, supporting temperature ranges from -40°C to +75°C. With open Linux platform, high processing power, and multiple industrial protocols, it enables scalable IoT deployments for traffic control, meters, and industrial automation. Easy setup via web management tools makes it ideal for remote and critical industrial applications.
Buy Advantech ICR-3201W gateway now and enhance your industrial IoT connectivity with robust serial, Ethernet, Wi-Fi, and Bluetooth features.
Frequently Asked Questions
Where can I buy Advantech Automation ICR3201W?
You can click on the BUY or RFQ button to purchase ICR3201W from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part ICR3201W?
You can download the ICR3201W datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of ICR3201W?
Advantech Automation
