Advantech Automation OPT8HAE PCI Communication Card
The PCI-1620 and PCI-1622 are high-performance PCI communication cards designed for reliable data transfer in industrial and multitasking environments. The PCI-1620 offers eight RS-232 ports, while the PCI-1622 supports eight RS-232, RS-422, or RS-485 ports. Both models feature high-speed UARTs with 256-byte FIFOs, supporting data rates up to 921.6 kbps and compliance with PCI 2.2 standards. They include surge, EFT, and isolation protections, are compatible with Windows XP/7/8/10 and Linux, and are suitable for industrial automation, data acquisition, and communication systems.
Advantech Automation OPT8HAE PCI Communication Card Specifications:
- Bus Type: PCI 2.2 compliant
- Connectors: Female DB62 (PCI-1620A/22A/22B), Female DB78 (PCI-1622C)
- Dimensions: 174.65 x 106.67 mm (6.88" x 4.2")
- Power Consumption: 260mA@+3.3V
- Supported OS: Windows XP/7/8/10, Linux
- Communication Controller: XR17V358 with 256-byte FIFOs
- Data Rates: up to 921.6 kbps supported at all ports
- Signals: RS-232 (TxD, RxD, RTS, CTS, DTR, DSR, DCD), RS-422 (Tx, Te, Rx), RS-485 (Data+, Data-), Flow Control: DTR/DSR, RTS/CTS, Xon/Xoff
- Protection: EFT, Surge, and Isolation up to 1000V
- Environmental: Humidity 5-95% RH, Temperature -10°C to 60°C, Storage -25°C to 85°C
- Accessories include DB25, DB9, and DB78 cabling options
- Certification: CE, FCC Class A
Buy the Industrial Control Components 8-port RS-232 PCI – Reliable Communication for Industrial Applications
Discover the PCI-1620 and PCI-1622 PCI communication cards, offering reliable, high-speed data transfer with multiple port options. Designed for industrial automation and data acquisition, these cards support RS-232, RS-422, and RS-485 protocols, with surge and EFT protections to ensure system safety. Compatible with Windows and Linux operating systems, they feature advanced UART technology with 256-byte FIFOs, supporting data rates up to 921.6 kbps. Invest in durable, compliant communication solutions for your industrial communication needs today.
Get PCI-1620 today—built for precision, fast data transfer, and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy Advantech Automation OPT8HAE?
You can click on the BUY or RFQ button to purchase OPT8HAE from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part OPT8HAE?
You can download the OPT8HAE datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of OPT8HAE?
Advantech Automation
