Advantech Automation ADAM6018D Thermocouple Temperature Module
The ADAM-6018D is a flexible eight-channel thermocouple temperature sensor module designed for environmental and facility monitoring. It supports protocols including MQTT with TLS, SNMP, Modbus TCP, UDP, RESTful API, and ASCII, offering versatile system integration. With basic logic control via GCL, peer-to-peer I/O status mapping, and an integrated watchdog timer, it ensures reliable performance. The module features a single RJ45 port, a 13-pin screw terminal, and a 9-pin connector for secure communication. Its robust design makes it ideal for precise temperature measurements in industrial environments.
Advantech Automation ADAM6018D Thermocouple Temperature Module Specifications:
- Channels: 8 differential thermocouple inputs
- Input Type: Thermocouple (Type J, K, B, T, etc.)
- Input Range: -200°C to 1372°C depending on type
- Input Impedance: Voltage >10MΩ
- Resolution: 16-bit
- Sampling Rate: 10 or 100 samples/second; high-speed mode 1K samples/second
- Wire Burnout Detection: Supported
- CMR @ 50/60 Hz: 90dB (standard), 60dB (high-speed)
- Output Delay: On: 100ps, Off: 150ps
- Power Consumption: 300mW
- Protocols Supported: Modbus TCP, MQTT with TLS, SNMP, UDP, RESTful API, ASCII
- Power Input: 24V DC ±10%
- Operational Temperature Range: -20°C to +70°C
- Storage Temperature Range: -25°C to +85°C
- Humidity: 20-95% RH (non-condensing)
- Isolation Protection: 2000V
- Connectors: RJ45, 13-pin, 9-pin screw terminals
- Built-in TVS/ESD Protection, Reversal Power Protection
Buy the Buy Industrial Environmental Monitoring Thermocouple Module Part Number ADAM6018D Online
Purchase the ADAM-6018D thermocouple temperature sensor module online for reliable, high-precision temperature measurement in industrial environments. Featuring 8 differential inputs, 16-bit resolution, and support for numerous protocols including Modbus TCP, MQTT, SNMP, and RESTful API, this versatile module ensures seamless integration with environmental monitoring systems. Its robust design includes Bluetooth connectivity, EtherNet/IP compatibility, and comprehensive protections like TVS and ESD. Ideal for HVAC, data centers, and industrial automation, it delivers accurate readings with excellent system reliability and ease of installation, making it a perfect choice for professionals.
Get ADAM-6018D thermocouple module today—built for precise temperature sensing and long-lasting industrial performance.
Frequently Asked Questions
Where can I buy Advantech Automation ADAM6018D?
You can click on the BUY or RFQ button to purchase ADAM6018D from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part ADAM6018D?
You can download the ADAM6018D datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of ADAM6018D?
Advantech Automation
