AMPHENOL COMMUNICATIONS SOLUTIONS 1014544510003MLF PCIe M.2 Connector
Amphenol ICC’s PCIe M.2 Gen 3 and Gen 4 card edge connectors offer high-density, high-performance connection solutions with 67 contacts on a 0.50mm pitch. Designed for PCIe 3.0, USB 3.0, and SATA 3.0 applications, these connectors support higher data rates up to 16Gb/s with upgradable options to Gen 4 for faster data transmission. They feature various heights and keying options, supporting both straight and angled insertion of M.2 modules. The durable design supports up to 5000 mating cycles, ensuring reliable performance in laptops, tablets, storage, and server applications.
AMPHENOL COMMUNICATIONS SOLUTIONS 1014544510003MLF PCIe M.2 Connector Specifications:
- Contact Material: Copper alloy with gold plating
- Contact Finish: Lead-free compatible
- Housing: UL 94 V-0 rated, lead-free suitable
- Electrical Resistance: Max 55mΩ initial, max 20mΩ change
- Insulation Resistance: >5 x 10^8Ω at 500V DC
- Dielectric Withstanding Voltage: >300V AC
- Current Rating: 0.5A per contact
- Voltage Rating: 50V AC
- Mechanical Durability: Up to 5000 mating cycles for gold-plated modules
- Operating Temperature: -40°C to +80°C
- Insertion Force: Max 20N
- Shock Resistance: Up to 285G in six axes
- Vibration Resistance: EIA-364-28, EIA-364-1000
- Packaging: Tape & Reel
- Length Options: Various heights and orientation support
Buy the Buy Amphenol PCIe M.2 Gen 3 and Gen 4 Card Edge Connectors Part Number 1014544510003MLF Online
Enhance your storage and computing systems with the versatile PCIe M.2 connector from Amphenol. Designed for PCIe 3.0 and 4.0, USB 3.0, and SATA 3.0 applications, it offers high data transfer speeds up to 16Gb/s. Features include various heights, keying options, and support for both straight and angled insertion to meet diverse design requirements. With a robust construction supporting up to 5000 mating cycles, this connector ensures superior durability and flexibility for laptops, tablets, servers, and storage devices. Purchase online today for reliable high-speed connectivity.
Order your Amphenol Series MDT350MOX001VT PCIe M.2 Connector today and ensure high-speed, reliable connections for your storage and computing projects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 1014544510003MLF?
You can click on the BUY or RFQ button to purchase 1014544510003MLF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 1014544510003MLF?
You can download the 1014544510003MLF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 1014544510003MLF?
AMPHENOL COMMUNICATIONS SOLUTIONS
