AMPHENOL COMMUNICATIONS SOLUTIONS 10147430113T0LF PCIe M.2 Card Edge Connector
Amphenol ICC’s PCIe M.2 Gen 3 and Gen 4 connectors are designed for high-density, high-performance applications. These connectors offer 67 contacts on a 0.50mm pitch, supporting higher data rates and reducing board space compared to PCIe Mini Card connectors. They are ideal for tablets, laptops, low-profile storage, and server applications, supporting PCIe 3.0, USB 3.0, and SATA 3.0 standards. The connectors are available in various heights and keying options, with some supporting both angled and straight insertion. Options for gold plating and vertical orientations are also available to meet diverse application needs.
AMPHENOL COMMUNICATIONS SOLUTIONS 10147430113T0LF PCIe M.2 Card Edge Connector Specifications:
- Contact: Copper alloy with gold plating
- Contact Finish: Compatible with lead-free soldering process
- Housing: Complies with UL 94 V-0
- Low Level Contact Resistance: 55m Ω max. (initial), 20m Ω max. change allowed
- Insulation Resistance: >5 x 108 Ω at 500V DC
- Dielectric Withstanding Voltage: >300V AC (RMS) at sea level
- Current Rating: 0.5A/Power contact (continuous)
- Voltage Rating: 50V AC per contact
- Durability: 25-60 mating cycles (normal M.2), 5000 mating cycles (with 30Au)
- Insertion Force: 20N max.
- Shock: 250 G (notebook), 285 G (tablet)
- Vibration: EIA-364-1000 Test group 3
- Operating Temperature: -40°C to +80°C
- Useful Field Life: Three (3) years
- Data Rate: Up to 16Gb/s (Gen 4)
Buy the 10147430-113T0LF AMPHENOL COMMUNICATIONS SOLUTIONS PCIe M.2 Card Edge Connector | myMectronic
Purchase the AMPHENOL COMMUNICATIONS SOLUTIONS 10147430-113T0LF PCIe M.2 Card Edge Connector securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 10147430113T0LF?
You can click on the BUY or RFQ button to purchase 10147430113T0LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 10147430113T0LF?
You can download the 10147430113T0LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 10147430113T0LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
