AMPHENOL COMMUNICATIONS SOLUTIONS 52601S204LF Connector System
The Quickie™ Connector System is a low-power, insulation piercing connector designed for printed wiring board-to-flat cable (round conductor) applications. Made of full-hard phosphor bronze with optional gold or tin plating, it features a two-piece design with a molded latch, optional strain relief, and optional polarizing features. The system ensures reliable electrical performance with a maximum current rating of 1.0 ampere, contact resistance not exceeding 10 milliohms, and insulation resistance of at least 50,000 megohms. It is suitable for environments with humidity, vibration, thermal shock, and exposure to chemicals, ensuring durability and consistent performance in industrial settings.
AMPHENOL COMMUNICATIONS SOLUTIONS 52601S204LF Connector System Specifications:
- Material: Full-hard phosphor bronze for contacts
- Plating: Gold or tin on contacts, nickel underplate
- Current Rating: 1.0 A DC
- Contact Resistance: ≤ 10 milliohms
- Insulation Resistance: ≥ 50,000 megohms
- Dielectric Voltage: ≥ 1,000 VRMS
- Temperature Range: -65°C to +105°C
- Cable Compatibility: AWG 28 stranded or AWG 30 solid
- Environmental Resistance: Humidity, vibration, thermal shock
- Mechanical: 100 mating cycles durability, contact separation force ≥ 25 grams
Buy the Generic Connector System – Reliable Insulation Piercing for Industrial Applications
Purchase the versatile and reliable connector system online today to ensure secure, high-performance connections for printed wiring boards and flat cable applications. Designed for low-power industrial use, it features durable phosphor bronze contacts with optional gold or tin plating, and a two-piece construction for easy assembly and maintenance. Withstanding humidity, vibration, and thermal shock, this connector guarantees consistent electrical performance over numerous mating cycles. Convenient online ordering ensures fast delivery, supporting your project timelines with trusted, high-quality components engineered for durability and efficiency.
Get Generic Connector System today—built for precision and long-lasting durability, ideal for printed wiring board and flat cable connections in industrial environments.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 52601S204LF?
You can click on the BUY or RFQ button to purchase 52601S204LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 52601S204LF?
You can download the 52601S204LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 52601S204LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
