AMPHENOL COMMUNICATIONS SOLUTIONS 76342302LF Dubox Shunts
AMPHENOL's Dubox Shunts are robust board-to-board connectors designed for reliable connections in a variety of industrial applications. These connectors feature dual-beam contacts, ensuring a secure and stable connection. The slotted cutout in the low-profile housing simplifies electrical testing, while the stackable design allows for efficient use of space. They are ideal for applications requiring high reliability and ease of testing.
AMPHENOL COMMUNICATIONS SOLUTIONS 76342302LF Dubox Shunts Specifications:
- Housing: High temperature, black thermoplastic
- Flammability rating: UL94V-0
- Pin: Phosphor-bronze
- Plating: Gold or tin over 1.27μm (50μin.) nickel
- File no.: E66906
- File no. LR46923: LR46923
- Current rating: 2.5A max. per contact
- Insulation resistance: 50,000MΩ min
- Contact resistance: 15MΩ max. initial, 20MΩ max. after environmental tests
- Dielectric withstanding voltage: 800V
- Operating temperature range: -65°C to +125°C
- Mating cycles (durability): 50-Gold, 25-Tin
- Insertion force (gold contact): 450gf max.
- Insertion force (tin-lead contact): 500gf max.
- Withdrawal force (gold contact): 30gf min.
- Withdrawal force (tin-lead contact): 30gf min.
- Insertion depth: 4.85 mm (.191in.) min.
- Wipe: provides 3.81 mm (.015in.) wipe
Buy the 76342-302LF AMPHENOL COMMUNICATIONS SOLUTIONS Dubox Shunts | myMectronic
Securely purchase the AMPHENOL 76342-302LF Dubox Shunts online for reliable connectivity in your projects.
Buy Now
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 76342302LF?
You can click on the BUY or RFQ button to purchase 76342302LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 76342302LF?
You can download the 76342302LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 76342302LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
