AMPHENOL COMMUNICATIONS SOLUTIONS 76384309LF Vertical Receptacle
The product is a low-profile vertical receptacle with a pre-stressed, dual-beam contact design that ensures low insertion force and reliable signal protection. Made from high-temperature, glass-filled thermoplastic polyester, it features gold or tin plating over nickel, and supports a dielectric withstanding voltage of 1000V RMS. Suitable for PCB mounting, it withstands operating temperatures from -65°C to +125°C, offers 200 mating cycles, and is RoHS compliant. Designed for both top and dual entry configurations, it ensures easy assembly and durability in electronic applications.
AMPHENOL COMMUNICATIONS SOLUTIONS 76384309LF Vertical Receptacle Specifications:
- Housing Material: Glass filled thermoplastic polyester
- Housing Color: Blue
- Flammability Rating: UL94V-0
- Pin Material: Phosphor-bronze
- Plating: Gold or tin over 1.27µm nickel
- Electrical Rating: 3A DC max. per contact, 2A fully energized
- Insulation Resistance: 1x 10^9Ω min.
- Contact Resistance: 15mΩ initial, 20mΩ after environmental tests
- Dielectric Withstanding Voltage: 1000V RMS
- Operating Temperature Range: -65°C to +125°C
- Mating Cycles: 200
- Insertion Depth: 3.6mm min. to 6.81mm max. (top entry), 6mm min. (bottom entry)
- RoHS Compatible
Buy the Fci Series Vertical Receptacles: PCB Connector 76384309LF
Order the Fci vertical receptacle 76384309LF online today to benefit from high durability, low insertion force, and excellent signal integrity. These connectors are designed for reliable PCB connections with a robust construction, RoHS compliance, and versatile top and dual entry options. Perfect for industrial, consumer, or automotive electronics, this high-temperature, glass-filled thermoplastic housing ensures excellent performance in challenging environments. Take advantage of easy online purchase and fast delivery to improve your electronic system assembly today.
Buy Fci vertical receptacles 76384309LF now and experience unmatched reliability and performance in electronic assembly.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 76384309LF?
You can click on the BUY or RFQ button to purchase 76384309LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 76384309LF?
You can download the 76384309LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 76384309LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
