AMPHENOL COMMUNICATIONS SOLUTIONS 98424G5216ALF Double-Row Card Connector
The Minitek II connector is a double-row, vertical card connector designed for use with 2.0mm center-to-center holes, available in vertical and right-angle orientations. Made from high-quality materials including phosphor bronze and glass-filled polymers with UL 94V-0 flammability rating, it features gold, nickel, palladium-nickel plating, and a durable housing. Rated for 200V AC/DC and 2A, it operates from -40°C to 125°C, with excellent electrical, mechanical, and environmental performance, including vibration, thermal shock, humidity, and salt spray resistance, ensuring reliable connections in demanding applications.
AMPHENOL COMMUNICATIONS SOLUTIONS 98424G5216ALF Double-Row Card Connector Specifications:
- Material: Phosphor Bronze, Glass-filled PBT and PCT
- Finish: Gold, Nickel, Palladium-Nickel platings, UL 94V-0 flammability rated
- Pin Material: Phosphor Bronze; Housing Color: Black/Beige
- Operating Voltage: 200V AC/DC
- Max Current: 2A
- Operating Temperature Range: -40°C to 125°C
- Vibration: MIL-STD-202, Method 201A, 2-55-10 Hz, 1.5mm amplitude
- Salt Spray: MIL-STD-202, Method 101D, 48 hours
- Thermal Shock: MIL-STD-202, Method 107D, 5 cycles of -55°C to 105°C
- Insulation Resistance: Min 100 MΩ at 500V DC
- Contact Resistance: Max 25 mΩ
- Dielectric Withstanding Voltage: 650V AC for 1 minute
- Temperature Rise: Max 30°C at 2A
- Vibration and Mechanical durability confirmed
- Post Retention Force: Min 1.0 kg
Buy the Buy FCI Minitek II Connector Part Number 98424G5216ALF Online
Order the FCI Minitek II connector online today to ensure reliable, high-performance connections for your electronic projects. Designed for durability and environmental resistance, this high-quality connector features gold and nickel-plated contacts, UL 94V-0 rated housing materials, and operating voltage up to 200V with 2A current capacity. Suitable for demanding environments, it withstands vibration, thermal shock, humidity, and salt spray conditions. Easy to install and ideal for various applications requiring dependable electrical connectivity in compact spaces.
Get FCI Minitek II connector today—built for precision and long-lasting durability in demanding electronic applications.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 98424G5216ALF?
You can click on the BUY or RFQ button to purchase 98424G5216ALF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 98424G5216ALF?
You can download the 98424G5216ALF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 98424G5216ALF?
AMPHENOL COMMUNICATIONS SOLUTIONS
