AMPHENOL COMMUNICATIONS SOLUTIONS L17RRD2M01100 D-Sub Connector
The RR-HR series crimp connectors are high-performance, rear release D-Sub connectors featuring stamped and formed contacts, suitable for industrial and telecom applications. Made with tin-plated steel shells and black thermoplastic insulators, these connectors support wire sizes from 20 to 28 AWG, with a current rating of 5A and voltage rating of 500V AC/rms. Designed for high volume production, they offer excellent EMI/RFI shielding, removable contacts, and compatibility with automated tooling. Operable within -55°C to +125°C, these durable connectors are ideal for reliable, high-density signal termination in demanding environments.
AMPHENOL COMMUNICATIONS SOLUTIONS L17RRD2M01100 D-Sub Connector Specifications:
- Shell Material: Tinned steel with or without dimples
- Insulator: Black glass-filled thermoplastic, UL 94V-0
- Contacts Material: Brass with gold or nickel plating, gold flash or tin
- Contact Resistance: 10mΩ max
- Wire Size: 20-28 AWG max insulation
- Current Rating: 5A
- Voltage Rating: 500V AC/rms 50Hz
- Withstanding Voltage: RR: 1000V AC/rms 50Hz for 1 minute, HR: 1000V AC/rms 60Hz for 1 minute
- Insulation Resistance: RR: 5000MΩ, HR: 1000MΩ
- Operating Temperature: -55°C to +125°C
- Mating Force: Varies by contact size, approx. 3.05 to 15 kg
- Unmating Force: Varies, approx. 0.36 to 2.02 kg
- Dimensions: Compatible with standard D-Sub configurations, shell thickness suitable for high-density and standard density mounting
- RoHS Compliant: Yes
Buy the Amphenol RR-HR – Reliable D-Sub Connectors for Industrial Applications
Order Amphenol RR-HR D-Sub connectors online today and benefit from high-quality, durable, and reliable connections. Designed for high-volume production, these connectors feature rear release, stamped contacts, and excellent EMI/RFI shielding. Supported with automated tooling compatibility, they support wire sizes from 20 to 28 AWG and operate in temperatures ranging from -55°C to +125°C. Perfect for industrial, telecom, and control system applications, ensure optimal signal integrity with these high-density, RoHS-compliant connectors that guarantee secure, consistent connections for demanding environments.
Buy Amphenol RR-HR connectors now and experience unmatched reliability and performance in high-volume industrial and telecom projects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS L17RRD2M01100?
You can click on the BUY or RFQ button to purchase L17RRD2M01100 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part L17RRD2M01100?
You can download the L17RRD2M01100 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of L17RRD2M01100?
AMPHENOL COMMUNICATIONS SOLUTIONS
