AMPHENOL COMMUNICATIONS SOLUTIONS L77HDEH15SOL2RM5 D-Sub Connector
The Amphenol SD series high-density and standard-density D-Sub connectors feature precision-formed contacts, UL 94V-0 thermoplastic insulators, and plated steel shells. Designed for reliable solder-cup termination, these connectors support applications requiring current ratings up to 5A, voltage ratings of 250V AC, and withstand voltages of 1000V AC. Operating across -55°C to +125°C, they offer robust mechanical and climatic performance, including salt spray resistance and durable contact resistance. Ideal for industrial and telecom use, the series emphasizes quality, reliability, and compatibility with industry standards.
AMPHENOL COMMUNICATIONS SOLUTIONS L77HDEH15SOL2RM5 D-Sub Connector Specifications:
- Shell Material: Steel, tin over nickel plating
- Insulator Material: Glass-filled thermoplastic, UL 94V-0
- Contacts: Brass, gold in mating area; tin over nickel in termination
- Current Rating: 5A (Standard Density), 3A (High Density)
- Voltage Rating: 250V AC/rms 50Hz
- Withstanding Voltage: 1000V AC/rms 50Hz for one minute
- Insulation Resistance: 1000MQ at 500V DC
- Contact Resistance: Max 20mΩ
- Operating Temperature: -55°C to +125°C
- Salt Spray Resistance: 24 hours
- Mechanical: Single contact insertion force 0.54kg max, withdrawal force 0.06kg min
- Mating/Unmating Force: Max 3.81kg / Min 0.52kg (SD), Max 5.95kg / Min 1.05kg (HD)
- Dimensions: Contact sizes range from 9 to 78 contacts, various mm measurements provided
- Plating Thickness: Gold flash, 0.4μm (15μ”) gold, 0.76μm (30μ”) gold
- RoHS Compliant
- Mounting: Panel mounting with #4-40 screwlock or M3 screw options
- Receptacle Shell Options: Tinned shell, with or without dimples
- Connector Configuration: Plug or socket, various arrangements
Buy the Amphenol Series SD D-Sub Connector: L77HDEH15SOL2RM5
Get your Amphenol SD series D-Sub connector today and enjoy fast, secure online purchasing. Designed for industrial and telecom uses, these connectors feature precision contacts, UL-rated thermoplastic insulators, and durable plated steel shells. They support high current and voltage ratings, withstand harsh environmental conditions, and offer easy panel mounting options. Order now to benefit from quality, reliability, and comprehensive technical support, ensuring your connection needs are met with industry-leading standards.
Buy Amphenol SD high-density and standard-density D-Sub connectors online now and experience unmatched reliability and performance in industrial and telecom applications.
