AMPHENOL COMMUNICATIONS SOLUTIONS L77TSBH25SOL2RM8 PCB Mount Connector
The Amphenol SD series connectors are high-quality, precision-formed PCB mount connectors available in standard and high-density variants. They feature stamped and formed contacts with closed-entry contact cavities, ensuring reliable electrical performance and secure connections suitable for industrial, telecom, and standard connections. Constructed with UL 94V-0 thermoplastic insulators and gold-plated brass or phosphor bronze contacts, these connectors support current ratings up to 5A and voltage ratings of 250V AC/rms. With robust mechanical and climatic specifications, they are ideal for durable, high-performance applications.
AMPHENOL COMMUNICATIONS SOLUTIONS L77TSBH25SOL2RM8 PCB Mount Connector Specifications:
- Current rating: Standard Density 5A, High Density 3A
- Voltage rating: 250V AC/rms, Withstanding voltage: 1000V AC/rms for one minute
- Contact resistance: 20mΩ max
- Operating temperature: -55°C to +125°C
- Mechanical: Contact insertion force SD 0.06kg min, HD 0.02kg min
- Dimensions vary by model: SD contacts 9-50, HD contacts 15-78, with overall dimensions specified in chart
- Materials: Steel shells, UL 94V-0 thermoplastic insulator, gold-plated brass contacts, phosphor bronze contacts
- Plating: Gold flash 0.38-0.76 μm; nickel over tin on contacts
- Environmental: Salt spray resistance 24 hours
Buy the Amphenol Series SD Connector: L77TSBH25SOL2RM8
Experience the durability and precision of the Amphenol SD series PCB mount connector. Designed for industrial and telecom applications, these connectors provide reliable electrical performance, robust construction, and high-density options. Suitable for standard and high-density uses, they feature gold-plated contacts to ensure excellent conductivity and corrosion resistance. Easy to install, with specifications supporting high current and voltage ratings, making them ideal for demanding environments. Purchase online now to ensure your projects have reliable, high-quality connectivity solutions designed for long-term use.
Get Amphenol SD connector series L77TSBH25SOL2RM8 today—built for high reliability, precision electrical performance, and long-lasting durability.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS L77TSBH25SOL2RM8?
You can click on the BUY or RFQ button to purchase L77TSBH25SOL2RM8 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part L77TSBH25SOL2RM8?
You can download the L77TSBH25SOL2RM8 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of L77TSBH25SOL2RM8?
AMPHENOL COMMUNICATIONS SOLUTIONS
