AMPHENOL COMMUNICATIONS SOLUTIONS MRJ258610BP Industrial Ethernet Connector
The MRJ258610BP is a rugged, high-performance modular jack designed for industrial and harsh environment applications. It features a right-angle PCB tail with 8 contacts, EMI ferrite filtering, and dust covers for enhanced protection. Suitable for IP67-rated environments, this connector supports Ethernet data rates up to 100BaseT. Made with high-quality thermoplastic and metal components, it is RoHS compliant and engineered for durability, vibration resistance, and reliable electrical performance. Ideal for military, medical, and high-tech networking setups requiring secure and robust connections.
AMPHENOL COMMUNICATIONS SOLUTIONS MRJ258610BP Industrial Ethernet Connector Specifications:
- Termination Style: Right Angle PCB with dust cover
- Number of Contacts: 8
- Contact Resistance: 30 mΩ max
- Insulation Resistance: 500 MΩ minimum
- Dielectric Withstand Voltage: 1000/1500 V AC
- Current Rating: 1.5A per contact
- Operating Temperature: -40°C to +105°C
- Material: Phosphor Bronze contacts, high-temp thermoplastic housing, die cast zinc shell
- Humidity: Per EIA 512-6 / EIA 364-11A
- Vibration: Per EIA 364-28, Condition 5A
- Salt Spray: 250 hours per EIA 364-26
- Mating Cycles: 2500
- Soldering: Wave solder at 265°C for 8 seconds, suitable for PCB thickness 1.57-3.18 mm
- RoHS Compliant
- Compatible with Ethernet/IP, 10BaseT, 100BaseT
Buy the Amphenol MRJ258610BP – Reliable Industrial Ethernet Connector for Harsh Environments
Order the durable Amphenol MRJ258610BP online today to ensure secure, high-performance Ethernet connections in tough industrial and military environments. This rugged modular jack features EMI filtering, dust covers, and IP67 rating, making it ideal for harsh conditions. With 8 contacts and high-quality materials, it provides reliable electrical performance, vibration resistance, and long-term durability. Perfect for medical equipment, military vehicles, and industrial automation—purchase now for fast delivery and confident installation.
Buy Amphenol MRJ258610BP now and experience unmatched reliability, EMI filtering, and IP67 protection for demanding industrial networking setups.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS MRJ258610BP?
You can click on the BUY or RFQ button to purchase MRJ258610BP from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part MRJ258610BP?
You can download the MRJ258610BP datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of MRJ258610BP?
AMPHENOL COMMUNICATIONS SOLUTIONS
