AMPHENOL COMMUNICATIONS SOLUTIONS MUSBB15134 Mini USB Type-B Receptacle
The MUSBB15134 is a right-angle Mini USB Type-B receptacle designed for reliable connections in computing applications. It features gold-plated phosphor bronze contacts compliant with USB 2.0 standards, supporting data transfer rates up to 480 Mbps. The connector has five contacts arranged in a 5-position configuration and employs through-hole mounting for secure attachment. Its sturdy construction includes a rear shield with #2-56 UNC thread and an adhesive-backed PORON gasket for sealing against dust and moisture. Manufactured with quality thermoplastic housing, it is durable in harsh environments and supports applications like computers, peripherals, and industrial equipment, ensuring optimal performance with low contact resistance of 50 milliohms, meeting industrial standards for vibration, shock, humidity, and temperature resistance.
AMPHENOL COMMUNICATIONS SOLUTIONS MUSBB15134 Mini USB Type-B Receptacle Specifications:
- Type: Mini USB Type-B
- Orientation: Right Angle
- Number of Contacts: 5
- Contact Material: Gold-plated phosphor bronze
- Support: USB 2.0, up to 480 Mbps
- Mounting Style: Through-hole
- Threads: #2-56 UNC threaded rear shield
- Gasket: Adhesive-backed PORON for sealing
- Housing Material: Thermoplastic, UL94V-0 rated, black
- Contact Resistance: Max 50 milliohms
- Temperature Range: -40°C to +105°C
- Environmental Resistance: Vibration, shock, humidity resistance
- Application: Computers, peripherals, industrial devices
- Durability: Supports up to 1500 mating cycles
Buy the Buy Amphenol Mini USB Type-B Receptacle Part Number MUSBB15134 Online
Purchase the Amphenol MUSBB15134 Mini USB Type-B right-angle receptacle online today. Designed for durability and sealed against dust and moisture, it supports USB 2.0 data transfer at 480 Mbps. Its robust construction includes gold-plated contacts, a rear shield with #2-56 UNC thread, and an adhesive-backed gasket for sealing. Perfect for computers, peripherals, and industrial equipment, this connector supports up to 1500 mating cycles, operates in harsh environments, and ensures low contact resistance of 50 milliohms. Secure your electronic devices with this high-quality, reliable USB solution available for online purchase now.
Buy Amphenol MUSBB15134 now and experience reliable connections and sealed protection for industrial and computer applications.
