Amphenol-Communications-Solutions T816150A1R101CEU phenol latch header
The T816 phenol latch header is a 2.54mm pitch connector designed for PCB applications, available in grey or black housing colors with various pin counts from 6 to 64. Features include gold or tin plating, straight or right-angled terminations, and ROHS compliance. Made with PBT+25%G.F insulator and brass contacts, it ensures high insulation resistance, current rating up to 3.0A, and voltage ratings of 250V AC/DC. Operating temperature ranges from -40°C to +105°C, suitable for reliable electrical connections.
Amphenol-Communications-Solutions T816150A1R101CEU phenol latch header Specifications:
- Pitch: 2.54mm
- Housing Colors: Grey, Black
- Number of Positions: 6, 8, 10, 14, 16, 18, 20, 24, 26, 32, 35, 40, 48, 60, 64
- Material Insulator: PBT+25%G.F, UL 94V-0
- Contact Material: Brass, Gold or Tin Plated Over 50u" Ni
- Electrical Resistance: 20 mΩ max at 1A
- Insulation Resistance: 1000 MΩ min at 500V/DC
- Dielectric Withstanding Voltage: 500V RMS, 60Hz for 1 min
- Current Rating: 3.0A max
- Voltage Rating: 250V AC/RMS 60Hz, DC
- Operating Temperature: -40°C to +105°C
Buy the Berg Series 7816 Phenol Latch Header: T816150A1R101CEU
Discover the Berg Series phenol latch header, a high-quality 2.54mm pitch connector available in various pin counts, featuring gold or tin plating for durability. Its robust PBT+G.F insulator and brass contacts ensure excellent electrical insulation and resistance to high temperatures from -40°C to +105°C. Ideal for reliable PCB connections, it is ROHS compliant and rated for 3A and 250V, making it an excellent choice for industrial electronics, automation systems, and reliable manufacturing parts. Purchase online today for fast delivery and trusted quality.
Buy Berg Series 7816 phenol latch header now and experience unmatched reliability and performance in PCB electrical connections.
Frequently Asked Questions
Where can I buy Amphenol-Communications-Solutions T816150A1R101CEU?
You can click on the BUY or RFQ button to purchase T816150A1R101CEU from an authorized Amphenol-Communications-Solutions distributor.
How do I troubleshoot issues or seek technical support for part T816150A1R101CEU?
You can download the T816150A1R101CEU datasheet or visit the Amphenol-Communications-Solutions website for support.
Who is the manufacturer of T816150A1R101CEU?
Amphenol-Communications-Solutions
