Apem Q22F1ABXXB12AE LED Indicator
The Q22F1ABXXB12AE is a 22mm panel mount LED indicator featuring a bright chrome bezel, designed for applications requiring high visibility and durability. It offers various mounting and termination options, including solder lug, faston terminals, rear epoxy wires, and short body pins. The LED provides a forward voltage of 5.7V for red, with a luminous intensity of 465mcd, suitable for panel sealing with IP67 option. It operates between -40°C to +85°C, with a life expectancy of 100,000 hours, ideal for industrial status indication and control panels.
Apem Q22F1ABXXB12AE LED Indicator Specifications:
- Diameter: 22mm (0.866 inch)
- Bezel Finish: Bright Chrome
- Mounting Hole Size: 22mm
- Terminals: Solder lug, faston, rear epoxy wires, short body pins
- Ingress Protection: IP67 (optional)
- Operating Temperature: -40°C to +85°C
- Forward Voltage: 5.7V (Red), 6.0V (Green), 5.9V (Yellow), 9.9V (Blue), 3.3V (White)
- Luminous Intensity: Red 465mcd, Green 245med, Yellow 365med, Blue 120med, White 150med
- Life Expectancy: 100,000 hours
- Voltage Range: 3.3V to 264VDC, 99V to 253VAC depending on model
- Viewing Angle: 30-100 degrees
- Temperature Range: -40°C to +85°C
- Material: ABS plastic bezel, polycarbonate rear body
- Sealing: IP67 (with option), general indicator, long lifespan
Buy the Buy APEM LED Indicator Part Number Q22F1ABXXB12AE Online
Enhance your control panel with this durable 22mm LED indicator designed for industrial environments. Features a bright chrome bezel, IP67 sealing option, multiple terminal configurations, and a long lifespan of 100,000 hours. Suitable for panel sealing and high visibility applications, it operates across a wide voltage range and is ideal for status indication in demanding conditions. Easy to install with various mounting options, ensuring reliable operation and clear visibility in harsh environments.
Buy APEM LED Indicator Part Number Q22F1ABXXB12AE now and experience unmatched reliability and performance for industrial control panels.
Frequently Asked Questions
Where can I buy Apem Q22F1ABXXB12AE?
You can click on the BUY or RFQ button to purchase Q22F1ABXXB12AE from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part Q22F1ABXXB12AE?
You can download the Q22F1ABXXB12AE datasheet or visit the Apem website for support.
Who is the manufacturer of Q22F1ABXXB12AE?
Apem
