BEL POWER SOLUTIONS 24RCM15024DMQ railway power converter
The RCM15024DMQ series are reliable 150 W DC-DC converters designed for railway and transportation systems. They operate with input voltages from 16.8 V to 45 V DC and deliver a stable 24 V output at a nominal current of 6.25 A. Features include high efficiency up to 93%, low inrush current, overvoltage, overtemperature, and reverse polarity protection. The units have a compact aluminum case with IP30 protection, supporting harsh environments per railway standards EN 50155. These converters are suitable for demanding industrial and transportation applications, ensuring robust and safe power supply with multiple options such as remote shutdown, output monitoring, and redundancy protection.
BEL POWER SOLUTIONS 24RCM15024DMQ railway power converter Specifications:
- Input Voltage Range: 16.8 V to 45 V DC
- Output Voltage: 24 V
- Output Power: 150 W
- Output Current: 6.25 A
- Efficiency: Up to 93%
- Input Capacitance: 40-10 μF depending on model
- Input Resistance: 100 mΩ
- Inrush Current: 75-100 A
- Operating Temperature Range: -40°C to 70°C
- Protection: Overvoltage, overtemperature, reverse polarity, short circuit
- Case Material: Aluminum, IP30 rated
- Switching Frequency: Approximately 120 kHz
- Size: Approximately 520 g (RCM150) with options for K connectors
- Standards Compliance: EN 50155, EN 50121-3-2, EN 45545, UL/CSA 60950-1
Buy the Bel Power Series RCM15024DMQ: 150 W Railway DC-DC Converter
Order the Bel Power RCM15024DMQ railway power converter online today and experience unparalleled reliability, efficiency up to 93%, and robust protection features. Designed to meet strict railway standards including EN 50155 and EN 45545, this 150 W converter provides stable 24 V output with low inrush current and comprehensive safety protections such as overvoltage, overtemperature, and reverse polarity. Its compact aluminum case ensures durability in harsh environments, while optional features like remote shutdown, output monitoring, and redundancy protect your critical systems. Perfect for demanding industrial and transportation applications—order now for fast delivery and peace of mind.
Get Bel Power RCM15024DMQ today—built for railway reliability, efficiency, and long-lasting durability.
