BROADCOM APDS9500 Imaging Gesture Sensor
The APDS-9500 is an advanced imaging-based proximity and gesture sensor offering nine-gesture recognition, built-in proximity detection, and optical object sensing in a compact 18-pin package. Equipped with a 30x30 or 60x60 pixel array and 9-bit grayscale output, it can detect motion in multiple directions and respond to gestures like move up, down, left, right, forward, backward, wave, and circle. Its flexible I2C-bus interface supports data rates up to 400 kHz, with integrated ambient light immunity, making it ideal for touch-screen disable, mechanical switch replacement, and gesture-based control applications.
BROADCOM APDS9500 Imaging Gesture Sensor Specifications:
- Imaging sensor: 30x30 or 60x60 pixels, 9-bit grayscale
- Gesture recognition: Nine gestures including move, circle, wave
- Proximity detection: Object approach/ depart, brightness, size output
- Interface: I2C-bus compatible, data rates up to 400 kHz
- Power supply: VDD 2.8V to 3.3V, Vopp range from 2.8V to 3.3V
- Physical dimensions: 6.87 x 3.76 x 2.86 mm (L x W x H)
- Operating temperature: -20°C to +70°C
- Package: 18-pin surface-mount module, moisture-proof sealed
- Optional modes: Gesture detection, proximity sensing, image output via SPI or I2C
- Features: Ambient light immunity, dedicated interrupt pin, flexible power saving modes
Buy the Buy Broadcom APDS-9500 Part Number APDS9500 Online
Order the Broadcom APDS-9500 imaging gesture and proximity sensor online today to enhance your design with nine-gesture recognition, optical object sensing, and a compact 18-pin package. Its flexible I2C interface supports data rates up to 400 kHz, ensuring fast and reliable data transfer. Ideal for touch-screen disable, mechanical switch replacement, and gesture-controlled devices, the APDS-9500 offers high sensitivity, ambient light immunity, and configurable modes. Experience effortless online purchasing and elevate your project’s interactivity with this reliable, high-performance sensor.
Buy Broadcom APDS-9500 now and experience unmatched reliability, gesture recognition accuracy, and seamless proximity detection for advanced interactive applications.
Frequently Asked Questions
Where can I buy BROADCOM APDS9500?
You can click on the BUY or RFQ button to purchase APDS9500 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part APDS9500?
You can download the APDS9500 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of APDS9500?
BROADCOM
