BROADCOM HCMS3906 Alphanumeric Display
This high-brightness, high-performance CMOS 5x7 alphanumeric display operates at 3.3V with a character height of 0.15 inches. It features direct microprocessor interfacing via serial input, convenient brightness control, and is built in a rugged, stackable package compatible with X- and Y- configurations. Suitable for telecommunications, portable data entry, medical devices, and industrial controls, it employs low power CMOS tech and TTL compatibility, ensuring reliable performance in diverse applications with easy integration and high readability.
BROADCOM HCMS3906 Alphanumeric Display Specifications:
- Operating Voltage: 3.3V
- Character Height: 0.15 inches
- Display Format: 5x7 pixel matrix
- Package: Rugged, stackable X- and Y- configurations
- Interface: Serial input, TTL compatible
- Brightness Control: Via Control Word 0
- Built with low power CMOS technology
- Application: Telecommunications, medical equipment, industrial controls
- Pin configuration: Includes Data In, Data Out, Clock, Reset, Brightness, and Power Pins
- Maximum junction temperature: 150°C
- Power Dissipation: 0.766W for 4-character, 1.532W for 8-character, 3.064W for 16-character display
- Soldering Temperature: 260°C for 5 seconds
- ESD Protection: 1.5 kΩ, 100 pF per pin
- Timing: Fast serial data loading with timing specifications aligned for reliable operation
Buy the Avago Technologies HCMS3906 – Reliable 5x7 alphanumeric display for industrial applications
Order the Avago Technologies HCMS3906 alphanumeric display today and enjoy quick delivery. This 3.3V CMOS 5x7 character model offers excellent readability, easy microprocessor interfacing, and durability suited for telecommunications, medical equipment, and industrial controls. Its rugged, stackable design ensures flexible integration into various systems. With low power consumption and high reliability, this device simplifies your design process while providing clear, vibrant characters for your applications. Enhance your project efficiency by purchasing online now.
Buy Avago Technologies HCMS3906 high-brightness CMOS display now and experience unmatched reliability and performance in your industrial and medical projects.
Frequently Asked Questions
Where can I buy BROADCOM HCMS3906?
You can click on the BUY or RFQ button to purchase HCMS3906 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HCMS3906?
You can download the HCMS3906 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HCMS3906?
BROADCOM
