BELDEN 96140601000 Shielded Computer Cable
The 9614 0601000 is a 304.8-meter, 9-core chrome shielded computer cable designed for EIA RS-232 applications. It features stranded tinned copper conductors, S-R PVC insulation, an overall Beldfoil® shield providing 100% coverage, a tinned copper braid shield with 65% coverage, and a PVC jacket. The cable supports up to 1.5 amps per conductor at 25°C, has an overall diameter of 0.256 inches, and withstands temperatures from -30°C to +80°C. It complies with UL, CSA, RoHS, WEEE, and other international standards, making it ideal for industrial and computer peripheral use.
BELDEN 96140601000 Shielded Computer Cable Specifications:
- Number of Conductors: 9
- Conductor Material: Tinned Copper
- Conductor Gauge: 24 AWG
- Insulation Material: S-R PVC
- Shielding: Beldfoil® 100% coverage, Tinned Copper Braid 65% coverage
- Outer Jacket: PVC
- Overall Diameter: 0.256 inches
- Operating Temperature Range: -30°C to +80°C
- Maximum Pulling Tension: 71 lbs (approx. 315.82 N)
- Rated Voltage: 300 V
- Compliance: UL 1685, CSA FT4, RoHS, WEEE, Eu LVD, EU RoHS
- Bulk Lengths Available: 100 ft, 1000 ft, 300 ft
- Weight: 40 lbs per 1000 ft
Buy the Buy Belden 9614 0601000 Part Number 96140601000 Online
Order the Belden 9614 0601000 shielded computer cable online for robust, high-quality EIA RS-232 data communication. This 9-core cable features stranded tinned copper conductors insulated with S-R PVC, with an overall Beldfoil® shield providing 100% coverage, plus a tinned copper braid shield with 65% coverage for superior EMI protection. With a PVC jacket, it supports environments from -30°C to +80°C. Certified for UL, CSA, RoHS, and WEEE compliance, it’s ideal for industrial control, peripherals, and high-reliability data transfer applications, ensuring long-lasting durability and stable performance.
Get Belden 96140601000 today—engineered for industrial environments and reliable data transmission.
Frequently Asked Questions
Where can I buy BELDEN 96140601000?
You can click on the BUY or RFQ button to purchase 96140601000 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 96140601000?
You can download the 96140601000 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 96140601000?
BELDEN
