C&K COMPONENTS SPA04B In-line Package Switch
The SPA Series Single In-line Package Switches are compact, RoHS compliant switches designed for industrial and computer logic control applications. They feature a push-button actuator with a mechanical and electrical life of at least 1,000 cycles, contact resistance ≤50 mΩ, and operating temperature from -30°C to 60°C. Constructed with durable PPS and PBT materials, these switches offer reliable switching at 10 mA @ 5V DC and are supplied in rigid tubes for convenient automation assembly. Suitable for address, logic, and function control in various electronic systems.
C&K COMPONENTS SPA04B In-line Package Switch Specifications:
- Contact Rating: Carry 10 mA @ 5VDC, Switching 0.1 mA @ 0.1m VDC min.
- Mechanical and Electrical Life: 1,000 cycles min.
- Contact Resistance: 50 mΩ max. @ 20 V DC 10mA.
- Insulation Resistance: 100 MΩ min. @ 100 V DC.
- Dielectric Strength: 1 minute @ 300 V AC.
- Capacitance: 5pF max. between adjacent terminals.
- Operating Temperature: -30°C to 60°C.
- Storage Temperature: -30°C to 80°C.
- Operating Force: 5.9 N max.
- Materials: Base PPS UL94V-0, Cover PBT UL94V-0, Actuator Nylon UL94V-0, Contacts Beryllium copper with gold over nickel plate.
- Termination: Dip & look solderability approved.
- Packaging: Supplied in rigid tubes, varies by model.
Buy the Buy C&K SPA Series Single In-line Package Switches Part Number SPA04B Online
Experience reliable switching performance with the C&K SPA Series In-line Package Switch. Designed for industrial controls, logic switching, and electronic applications, this switch offers durability with a minimum of 1,000 cycles and a contact resistance below 50 milliohms. Its construction from UL94V-0 rated materials ensures safety and longevity across operating temperatures from -30°C to 60°C. Packaged in convenient tubes for easy automation, it is ideal for address decoding, function control, and logic switching, providing dependable operation in compact designs.
Get C&K SPA04B today—built for reliable contact switching in industrial electronics and automation systems.
