DIODES INC. DMN3042L7 N-Channel MOSFET
The DIODES INC. DMN3042L-7 is an N-channel enhancement mode MOSFET engineered to minimize on-state resistance while maintaining superior switching performance. Its low gate threshold voltage and low input capacitance contribute to efficient power management in a variety of applications. Ideal for high-efficiency power management applications, DC-DC converters, portable power adaptors, and battery charging circuits, this MOSFET offers a robust and reliable solution. It is fully compliant with RoHS standards and is a halogen-free “Green” device.
DIODES INC. DMN3042L7 N-Channel MOSFET Specifications:
- V(BR)DSS: 30V
- RDS(ON) max: 26.5mΩ @ VGS= 10V
- ID max: 5.8A
- RDS(ON) max_2: 32mΩ @ VGS= 4.5V
- ID max_2: 5.0A
- Low On-Resistance: Yes
- Low Gate Threshold Voltage: Yes
- Low Input Capacitance: Yes
- Fast Switching Speed: Yes
- Low Input/Output Leakage: Yes
- RoHS Compliant: Yes
- Halogen Free: Yes
- Case: SOT23
- Case Material: Molded Plastic, “Green” Molding Compound
- Moisture Sensitivity: Level 1 per J-STD-020
- Terminals Finish: Matte Tin Annealed over Copper Leadframe
- Operating and Storage Temperature Range: -55 to +150 °C
- Drain-Source Voltage: 30V
- Gate-Source Voltage: ±12V
- Continuous Drain Current: 5.8A @ +25°C, 4.0A @ +70°C
- Maximum Body Diode Forward Current: 1.5A
- Pulsed Drain Current: 30A
- Power Dissipation: 0.72W
- Thermal Resistance, Junction to Ambient: 171 °C/W
- Power Dissipation_2: 1.4W
- Thermal Resistance, Junction to Ambient_2: 93 °C/W
- Gate Threshold Voltage: 0.6 - 1.4V
- Static Drain-Source On-Resistance: 21 - 26.5mΩ @ VGS= 10V
- Diode Forward Voltage: 0.7 - 1.2V
- Input Capacitance: 570 - 860pF
- Output Capacitance: 63 - 95pF
- Reverse Transfer Capacitance: 53 - 80pF
- Gate Resistance: 3.2 - 4.5Ω
- Total Gate Charge: 13.3 - 20nC @ VGS= 10V
- Turn-On Delay Time: 1.5 - 2.4ns
- Turn-Off Delay Time: 13.9 - 22ns
- Body Diode Reverse Recovery Time: 7.8 - 12ns
