DIODES INC. SB5100T Schottky Rectifier
The SB5100T is a high-efficiency Schottky barrier rectifier designed for low voltage, high-frequency inverters, free-wheeling, and polarity protection applications. It features guard ring die construction for transient protection, low power loss, and high surge capability with a peak surge overload rating of 150A. This lead-free, ROHS-compliant component has a molded plastic case with a UL 94V-0 flammability rating, bright tin-plated solderable terminals, and a cathode band for polarity identification. Suitable for resistive, inductive, and capacitive loads, it handles an operating temperature range of -65°C to +150°C and offers reliable performance in demanding electrical environments.
DIODES INC. SB5100T Schottky Rectifier Specifications:
- Peak Repetitive Reverse Voltage VRRM: 70-100 V depending on model
- Working Peak Reverse Voltage Vwen: 70-100 V
- DC Blocking Voltage VR: up to 100 V
- Average Rectified Output Current: 5.0 A
- Non-Repetitive Peak Forward Surge Current: 150 A (8.3ms, single half sine-wave)
- Forward Voltage @IF=5.0A: 0.80 V
- Peak Reverse Current @Ta=25°C: 0.5 mA
- Junction Capacitance: 400 pF
- Thermal Resistance Junction to Ambient: 10 K/W
- Operating and Storage Temperature Range: -65°C to +150°C
- Case: DO-201AD
- Material: Molded plastic, UL Flammability Rating: 94V-0
- Terminals: Bright tin-plated for soldering
- Moisture Sensitivity: Level 1 per J-STD-020C
- Dimensions: A 25.40 mm, B 7.20 - 9.50 mm, C 1.20 - 1.30 mm, D 4.80 - 5.30 mm
