FINDER 0720106 Level Control Relay
The product features level control relays designed for conductive liquids, supporting adjustable or fixed sensitivity, with functions for filling or emptying, LED indicator, reinforced insulation, and wall-mounting on a 35 mm rail. Suitable for monitoring liquid levels in tanks, these relays ensure safe operation through positive safety logic, controlling pumps or valves based on liquid levels between specified electrodes. Available with different voltage options, they are ideal for industrial automation and water treatment applications, offering reliable, precise, and safe level management.
FINDER 0720106 Level Control Relay Specifications:
- Supply Voltage: 24V DC, 24V AC 50/60 Hz, (110...125)V AC, (230...240)V AC, 400V AC (72.01 only)
- Rated current: 16A, Max peak current: 30A
- Contact configuration: 1 CO (SPDT)
- Rated voltage: 250V AC, Maximum switching voltage: 400V AC
- Rated load AC1: 4,000 VA, AC15 (230V AC): 750 VA
- Electrode resistance sensitivity: 5...150 kΩ (adjustable), fixed 150 kΩ
- Insulation dielectric strength: 6kV (between supply and contacts/electrodes)
- Ambient temperature: -20°C to +60°C
- Electrical life at rated load: 100,000 cycles
- Protection category: 1P20
- Dimensions: Designed for 35mm DIN rail mounting
- Electrode connection: Stainless steel, length options up to 500 mm, G3/8” thread
- EMC compliance per EN 61000 standards, IEC certification
Buy the Buy Finder 72 Series Level Control Relay Part Number 0720106 Online
Purchase your Finder 72 Series level control relay 0720106 online today for precise, safe, and reliable liquid level monitoring in industrial tanks. This relay offers adjustable sensitivity and filling or emptying functions, suitable for conductive liquids like water, sewage, and chemicals. Its reinforced insulation and positive safety logic guarantee safe operation, even during power failures. Designed for DIN rail mounting, it simplifies installation and maintenance. Get this essential control component now to optimize your liquid handling processes efficiently and securely.
Order your Finder 72 Series 0720106 level control relay today and ensure reliable liquid level management with adjustable sensitivity and safe operation features.
Frequently Asked Questions
Where can I buy FINDER 0720106?
You can click on the BUY or RFQ button to purchase 0720106 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 0720106?
You can download the 0720106 datasheet or visit the FINDER website for support.
Who is the manufacturer of 0720106?
FINDER
