Hammond Manufacturing 186F28 Power Transformer
This component is designed for power management and industrial applications, providing reliable performance in demanding environments. It features dual primary windings for 115/230 V operation, split bobbin construction, and is Hi-pot tested to 2 KV RMS, ensuring safety and durability. Suitable for chassis mounting, it includes quick connect and solder lug terminals, with insulation material rated at Class B or 130°C. UL recognized and CSA certified, it meets industrial standards and is ideal for reliable voltage transformation in various electrical systems.
Hammond Manufacturing 186F28 Power Transformer Specifications:
- Primary Voltage: 115/230 V
- Secondary Voltage: 28 V (VCT)
- Current Rating: 3.57 Amps
- Power Rating: 96 VA
- Dimensions: Length 4.03 inches, Height 2.25 inches, Terminal Centers 3.50 inches
- Construction: Split bobbin, open style, chassis mount
- Terminal Type: Quick connect, solder lug
- Insulation Material: Class B, 130°C rated
- Testing: Hi-pot tested to 2 KV RMS
- Certifications: UL recognized, CSA certified
- Temperature Rating: Designed to Class A temperature rise
Buy the Hammond 186F28 – Reliable Power Transformer for Industrial Applications
Purchase the Hammond 186F28 power transformer online today and ensure your electrical systems operate with dependable and efficient voltage conversion. This robust transformer features dual primary windings for 115/230 V operation, split bobbin construction for reduced electromagnetic interference, and high-quality insulation rated at Class B or 130°C. It is Hi-pot tested to 2 KV RMS for safety and reliability, UL recognized, and CSA certified. Easy to install with quick connect and solder lug terminals, making it an excellent choice for industrial control and power management systems.
Buy Hammond 186F28 now and experience unmatched reliability and power management in demanding industrial environments.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186F28?
You can click on the BUY or RFQ button to purchase 186F28 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186F28?
You can download the 186F28 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186F28?
Hammond Manufacturing
