INFINEON IM393S6E2XKLA1 Hybrid Power IC
The IM393-S6E is a compact, high-performance 600V/6A integrated hybrid IC designed for advanced appliance motor drives, such as energy-efficient fans, pumps, and washing machines. Utilizing low VCE(on) trench IGBT technology and industry-leading high-voltage, high-speed drivers, it features built-in temperature monitoring, over-current protection, and galvanic isolation up to 2000Vems. The device integrates gate drivers, bootstrap functionality, and thermal protections within a thermally enhanced, fully isolated package, simplifying design and ensuring fail-safe operation for low power motor applications across various household appliances.
INFINEON IM393S6E2XKLA1 Hybrid Power IC Specifications:
- Operating junction temperature: -40°C to 150°C
- Operating case temperature: -40°C to 125°C
- Storage temperature: -40°C to 125°C
- Isolation test voltage: 2000V RMS for 1 min
- Blocking voltage: 600V
- DC-link supply voltage: 450V (surge 500V)
- Peak output current: 9A
- Output current: 6A at 25°C
- Power dissipation per IGBT: 18W
- Gate driver supply voltage: 0 to 20V
- Input voltage (HIN, LIN, RFE, ITRIP): -0.3 to 20V
- Thermal resistance (case-heatsink): 0.25°C/W
- Mounting torque: 0.6-0.8 Nm
- UL Recognized, RoHS compliant, and qualified for industrial applications
Buy the Buy Infineon IM393-S6E Part Number IM393S6E2XKLA1 Online
Enhance your appliance motor control systems with the reliable and compact IM393-S6E hybrid power IC from Infineon. Designed for low power motor drives, it combines industry-leading low VCE(on) trench IGBT technology with integrated gate drivers, thermal protection, and high-voltage isolation suitable for washing machines, fans, and pumps. Its fully isolated package simplifies design, improves safety, and offers robust protection features, ensuring consistent performance and durability in household and industrial applications. Purchase online today for dependable, efficient motor drive solutions.
Order your Infineon SeriesIM393S6E IM393-S6E today and give your projects the dependable quality they deserve, optimized for energy-efficient motor control.
Frequently Asked Questions
Where can I buy INFINEON IM393S6E2XKLA1?
You can click on the BUY or RFQ button to purchase IM393S6E2XKLA1 from an authorized INFINEON distributor.
How do I troubleshoot issues or seek technical support for part IM393S6E2XKLA1?
You can download the IM393S6E2XKLA1 datasheet or visit the INFINEON website for support.
Who is the manufacturer of IM393S6E2XKLA1?
INFINEON
