JST B2PVHBLLFSN Shrouded Connector Header
This shrouded wall-mounted connector header from the VH Series features 6 positions with a 3.96mm pitch, rated for 250V. Made from copper alloy, tin-plated with reflow treatment, it is designed for reliable PCB connections in electronic assemblies. Suitable for applications requiring secure mounting and high current capacity, it complies with RoHS standards. The header is available in natural (white) color, with optional housing and color options. Its robust construction ensures durability and efficient electrical connection in consumer electronics and industrial equipment.
JST B2PVHBLLFSN Shrouded Connector Header Specifications:
- Current rating: 10A AC, DC (AWG #16)
- Voltage rating: 250V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/ 10mΩ max. After environmental testing/ 20mΩ max.
- Insulation resistance: 1,000MΩ min.
- Withstanding voltage: 1,500V AC/minute
- Applicable wire: AWG #22 to #16
- Applicable PCB thickness: 1.6mm
- Material: Phosphor bronze, tin-plated (reflow treatment)
- RoHS compliance
- Dimensions (mm): 3.96 (A), 7.86 (B)
- Pitch: 3.96mm
- Number of circuits: 6
- Color: Natural (white), optional color codes available
Buy the JST Series VH Connector Header: B2PVHBLLFSN
Order the JST Series VH Connector Header B2PVHBLLFSN online today and benefit from secure mounting, high current capacity, and RoHS compliance. Designed with durable copper alloy and tin-plated reflow treatment, this 6-position connector with a 3.96mm pitch offers reliable electrical connections for consumer electronics and industrial applications. Its compact design ensures easy integration into PCB assemblies, reducing assembly time while maintaining high standards of safety and performance. Secure your electronic projects with this dependable connector header available now for quick online order fulfillment.
Buy JST Series VH B2PVHBLLFSN now and experience unmatched reliability and performance in your electronic connections.
Frequently Asked Questions
Where can I buy JST B2PVHBLLFSN?
You can click on the BUY or RFQ button to purchase B2PVHBLLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B2PVHBLLFSN?
You can download the B2PVHBLLFSN datasheet or visit the JST website for support.
Who is the manufacturer of B2PVHBLLFSN?
JST
