JST BU12PTHRLFSN Wire-to-Wire Connector
A 12-position THR connector with a 2.5mm pitch offering reliable wire-to-wire connections. It supports both crimp style and insulation displacement receptacles, ensuring flexible termination options. The connector features an arm lock mechanism that provides a secure hold and easy release. Suitable for panel mounting on various thicknesses from 0.5 to 2.0mm, it is RoHS compliant and rated for 250V AC/DC. Made with high-quality materials for durability, this connector ensures stable electrical connections in demanding applications.
JST BU12PTHRLFSN Wire-to-Wire Connector Specifications:
- Current rating: Crimp style HR connectors type/3A AC, DC max. Insulation displacement HR connectors type/2A AC, DC max.
- Voltage rating: 250V AC, DC max.
- Temperature range: -25°C to +85°C.
- Contact resistance: Initial value/15mΩ @ max, after environmental testing/25mΩ max.
- Insulation resistance: 500MΩ min.
- Withstanding voltage: 1,000V AC/minute.
- Applicable wire: Crimp style HR connectors type/AWG #26 to #22 (0.13 to 0.33mm²); Insulation displacement HR connectors type/AWG #28, #26, #24.
- Applicable panel thickness: 0.5 to 2.0mm.
- Housing material: PA 66, UL94V-0, tin-plated housing, phosphor bronze contacts, RoHS compliant.
- Dimensions (mm): Model BU12P-THR: Length 34.1, Width 19.4, Height 12.5.
- Receptacle dimensions vary depending on model, with respective specifications for insertion and mating.
Buy the Buy JST THR Connector Part Number BU12PTHRLFSN Online
Purchase the JST BU12PTHRLFSN wire-to-wire connector online today for reliable, high-quality connections in your electrical projects. This model features a 12-position 2.5mm pitch with a robust arm lock mechanism ensuring a secure fit. Suitable for panel mounting on various thicknesses from 0.5 to 2.0mm, and rated for 250V AC/DC, it is RoHS compliant and constructed with durable materials for long-term performance. Whether for industrial automation, control systems, or consumer electronics, this connector provides versatility and dependable electrical connectivity.
Get JST BU12PTHRLFSN today—built for secure connections and long-lasting durability in your electronic systems.
Frequently Asked Questions
Where can I buy JST BU12PTHRLFSN?
You can click on the BUY or RFQ button to purchase BU12PTHRLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part BU12PTHRLFSN?
You can download the BU12PTHRLFSN datasheet or visit the JST website for support.
Who is the manufacturer of BU12PTHRLFSN?
JST
