JST PARP10VK Wire Socket
This is a 10-position wire-mounted socket with a 2mm pitch, designed in black. It features reliable contacts, a secure locking mechanism, and is suitable for complex wiring harnesses in electronic and industrial applications. Made with UL94V-0 rated materials, it supports current ratings up to 3A and voltage ratings of 250V AC/DC, ensuring safe electrical performance. The socket is compatible with AWG #28 to #22 wires, with dimensions optimized for durability and ease of assembly in various electronic assemblies.
JST PARP10VK Wire Socket Specifications:
- Number of Positions: 10
- Pitch: 2mm
- Material: UL94V-0 rated PA 66 housing, Copper alloy contacts
- Contact Resistance: Initial / 10mΩ max.
- Environmental Resistance: After testing / 20mΩ max.
- Insulation Resistance: 1,000MΩ min.
- Withstanding Voltage: 800V AC/minute
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Wire Compatibility: AWG #28 to #22
- Operating Temperature Range: -25°C to +85°C
- Dimensions (mm): A=20, B=74, c=58, D=55
- RoHS Compliant: Yes
Buy the JST Series PAF Wiring Socket: PARP10VK
Buy your JST Series PAF PARP10VK 10-position wire socket online today. Designed for robust electrical connections with a 2mm pitch, this socket offers secure locking, UL94V-0 rated housing, and support for up to 3A/250V. Its compatibility with AWG #28 to #22 wires makes it perfect for diverse electronic and industrial harnesses. Easy to assemble and highly reliable, this socket ensures durable performance, safety, and efficiency in your electronic assemblies, making it an essential component for engineers and technicians.
Order your JST Series PAF PARP10VK 10-position wire socket today and ensure reliable, safe connections for your electronic projects and industrial wiring.
Frequently Asked Questions
Where can I buy JST PARP10VK?
You can click on the BUY or RFQ button to purchase PARP10VK from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part PARP10VK?
You can download the PARP10VK datasheet or visit the JST website for support.
Who is the manufacturer of PARP10VK?
JST
