Johnson-Cinch Connectivity Solutions 1420694016 RF SMA Connector
This RF connector provides high-performance connectivity for 50 ohm impedance systems, ideal for high-frequency applications like 5G wireless, industrial RF, and communications infrastructure. It features a durable brass body, gold-plated contact surfaces, and a threaded SMA interface ensuring reliable, low-loss signal transmission up to 26.5 GHz. Its compact design includes a thread-on nut for secure attachment and is suitable for both semi-rigid and flexible cables. Designed for high durability, it withstands environmental stresses and maintains excellent electrical performance over multiple connection cycles, making it ideal for demanding RF environments.
Johnson-Cinch Connectivity Solutions 1420694016 RF SMA Connector Specifications:
- Impedance: 50 ohms
- Frequency Range: up to 26.5 GHz
- Insertion Loss: 0.03 f(GHz) (tested at 10 GHz)
- VSWR: 1.05 + 0.008f (w/o contact), 1.15 + 0.02f (with contact)
- Working Voltage: 250 Vrms (sea level)
- Dielectric Withstanding Voltage: 750 Vrms (for RG-316, LMR-100, 195, 200 cables)
- Power Rating: 0.5 watt at +25°C, derated to 0.25 watt at +125°C
- Durability: 500 cycles minimum
- Materials: Brass body with gold or nickel plating, brass or beryllium copper contacts
- Environmental Ratings: -65°C to +165°C, MIL-STD-202 environmental compliance
- Mechanical Ratings: Mating torque 7-10 inch-pounds, bulkhead nut torque 15 inch-pounds
- Sealing: Silicone rubber seals, conductive silicone gasket options available
- Connectors for RG-178, RG-316, LMR series cables ensure reliable performance in high-frequency RF transmission
