KEMET ALF20G223EH063 Aluminum Electrolytic Capacitor
The KEMET ALF20 Press-Fit aluminum electrolytic capacitor provides a reliable solderless connection suitable for high-voltage applications up to 63 VDC. Designed for durability, it supports high ripple currents, surge voltage capability, and offers a long operational life of up to 18,000 hours at +85°C. These compact, field-replaceable capacitors eliminate soldering issues like cold joints and are suitable for demanding environments. They have a capacitance of 22,000 uF, tolerance of 20%, a temperature range of -40/+85°C, and are available in bulk packaging for easy integration into various electronic assemblies.
KEMET ALF20G223EH063 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 22,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 63 VDC, 72.5 VDC (Surge)
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Dimensions: D 40mm +1mm, L 60mm +/-2mm, LL 5.5mm +/-1mm, F 1.486mm +/-0.076mm
- Style: Press-Fit
- RoHS Compliant: Yes
- Lead Type: 5 Pin Press-Fit
- Component Weight: 98 g
- Shelf Life: 156 Weeks
- Ripple Current: Rated at 85°C
- Leakage Current: 6000 uA (5min 20°C)
Buy the KEMET Series ALF20 Aluminum Electrolytic Capacitor: ALF20G223EH063
Purchase the KEMET ALF20G223EH063 aluminum electrolytic capacitor online today. Designed for high-voltage applications, it provides a reliable, solderless press-fit connection with a capacitance of 22,000 microfarads. Supporting voltages up to 63 VDC and operating over a temperature range of -40°C to +85°C, this durable capacitor is ideal for demanding electronic projects and industrial uses. Enjoy fast shipping and quality assurance when you buy online from authorized distributors.
Get KEMET ALF20G223EH063 today—built for high ripple current capacity and long-lasting durability in demanding electronic applications.
Frequently Asked Questions
Where can I buy KEMET ALF20G223EH063?
You can click on the BUY or RFQ button to purchase ALF20G223EH063 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALF20G223EH063?
You can download the ALF20G223EH063 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALF20G223EH063?
KEMET
