KEMET ALS40A473DF025 Aluminum Electrolytic Capacitor
The KEMET ALS40A473DF025 is a high-capacitance aluminum electrolytic capacitor designed for demanding applications requiring stable performance and reliability. With a capacitance of 47000uF and a voltage rating of 25VDC, this capacitor is suitable for power supplies, filtering, and energy storage in various industrial and commercial equipment. The screw terminal design ensures a secure and reliable connection, while the wide operating temperature range (-40°C to +105°C) allows for operation in harsh environments. KEMET’s ALS40 series is known for its robust construction and long life, making it a dependable choice for critical circuit applications.
KEMET ALS40A473DF025 Aluminum Electrolytic Capacitor Specifications:
- Series: ALS40
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- RoHS: Yes
- AEC-Q200: No
- Halogen Free: No
- Component Weight: 140 g
- Shelf Life: 156 Weeks
- Capacitance: 47000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 25 VDC
- Surge Voltage DC: 28.75 VDC
- Temperature Range: -40/+105°C
- Rated Temperature: 105°C
- Life: 6000 Hrs (Rated Voltage And Ripple Current At 105C), 10000 Hrs(Rated Voltage At 105C)
- Resistance: 9 mOhms (100Hz 20C), 8 mOhms(10kHz 20C)
- Ripple Current: 14 Amps (100Hz 105C), 14.7 Amps(10kHz 105C)
- Leakage Current: 3525 uA (5min 20°C)
- Sleeving: Yes
- Packaging: Bulk, Box
- Dimensions D: 36mm +/-1mm
- Dimensions L: 105mm +/-2mm
- Dimensions T: 7.1mm +/-0.5mm
- Dimensions S: 12.8mm +/-0.5mm
- Dimensions DT: 8mm +/-0.5mm
- Dimensions LT: 111.5mm +/-1mm
- Dimensions TD: 10mm MIN
- Dimensions V: 8mm NOM
Buy the ALS40A473DF025 KEMET Aluminum Electrolytic Capacitor | myMectronic
Purchase the KEMET ALS40A473DF025 with confidence and enjoy secure online ordering.
Buy Now
Frequently Asked Questions
Where can I buy KEMET ALS40A473DF025?
You can click on the BUY or RFQ button to purchase ALS40A473DF025 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS40A473DF025?
You can download the ALS40A473DF025 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS40A473DF025?
KEMET
