KEMET C44UQGT6760M87K industrial film capacitor
The C44UQGT6760M87K is a high-capacity film energy storage capacitor with a metallized polypropylene dielectric, rated at 760 uF with a 10% tolerance and a maximum DC voltage of 1100 V. Designed for DC filtering and energy storage applications, it features screw terminals M6, a can style enclosure, and a thermal resistance of 2.6°C/W. The compact dimensions include a diameter of approximately 85mm, a length of 268.5mm, and a weight of around 9.1kg. Suitable for industrial use, it offers a temperature range of -40°C to +85°C and an insulation resistance of 40 MOhms, ensuring reliable operation in demanding environments.
KEMET C44UQGT6760M87K industrial film capacitor Specifications:
- Capacitance: 760 uF
- Capacitance Tolerance: 10%
- Voltage DC: 1100 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 85mm +2mm, Length 268.5mm +/-2mm
- Weight: approximately 9.1kg
- Shell Style: Can
- Lead Terminals: M6 screw terminals
- Insulation Resistance: 40 MOhms
- Thermal Resistance: 2.6°C/W
- Max dVidt: 7 V/us
- Ripple Current: 70 Amps (lOkHz 40°C), 5550 Amps (Peak)
- Inductance: 80 nH
- Resistance: 2.3 mOhms (10kHz)
Buy the KEMET C44UQGT6760M87K – Reliable Energy Storage Capacitor for Industrial Applications
Secure your industrial equipment's power stability by purchasing the KEMET C44UQGT6760M87K online today. This high-capacity film capacitor offers 760 uF capacitance and 1100 VDC rating, ensuring reliable energy storage and filtering in demanding environments. With screw terminals M6, a sturdy can style enclosure, and broad temperature operation from -40°C to +85°C, it is perfect for industrial power systems. Achieve dependable performance with fast delivery and easy online ordering today.
Buy KEMET C44UQGT6760M87K now and experience unmatched reliability and high-performance energy storage for industrial DC filtering needs.
Frequently Asked Questions
Where can I buy KEMET C44UQGT6760M87K?
You can click on the BUY or RFQ button to purchase C44UQGT6760M87K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UQGT6760M87K?
You can download the C44UQGT6760M87K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UQGT6760M87K?
KEMET
