KYOCERA AVX 1001388 802.11a Antenna
Ethertronics’ Prestta series antennas utilize Isolated Magnetic Dipole (IMD) technology to address connectivity challenges in modern devices. The 1001388 model, part of this series, provides superior RF field containment, resists de-tuning, and enables smaller, more flexible designs. It’s ideal for applications like handsets, gateways, tablets, and M2M devices, offering improved range and sensitivity while maintaining brand loyalty. The antenna is RoHS compliant and designed for fast, low-cost manufacturing with its SMD mountable design.
KYOCERA AVX 1001388 802.11a Antenna Specifications:
- Peak Gain: < 7dBi
- Average Efficiency: 60%
- Return Loss in dB: -8dB max
- Feed Point Impedance: 50 ohms unbalanced
- Power Handling: 2 Watt CW
- Polarization: Linear
- Maximum Dimensions: 9.80mm x 4.2 mm x 2.2 mm
- Isolation between antennas: < -25dB
- Frequency Range: 4900-5900 MHz
Buy the 1001388 KYOCERA AVX 802.11a Antenna | myMectronic
Securely purchase the KYOCERA AVX 1001388 Prestta 802.11a antenna for your project today.
Buy Now
Frequently Asked Questions
Where can I buy KYOCERA AVX 1001388?
You can click on the BUY or RFQ button to purchase 1001388 from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part 1001388?
You can download the 1001388 datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of 1001388?
KYOCERA AVX
