L-COM HGLNCAT6J Ethernet Lightning Protector
The HGLN-CAT6J is an indoor shielded lightning protector designed for Ethernet networks supporting 10/100/1000 Base-T. Made from durable cast aluminum with shielded RJ-45 jacks, it offers superior lightning and surge protection, including both common and differential modes. Its ultra-low capacitance semiconductor arrays ensure high-frequency response and minimal signal distortion, making it ideal for IP cameras with PoE, wireless access points, bridges, and Gigabit network appliances. Compatible with 802.3af/at PoE standards, it effectively reduces EMI interference and features integral mounting for easy installation.
L-COM HGLNCAT6J Ethernet Lightning Protector Specifications:
- Ethernet Connectors: 2 shielded RJ45 jacks
- Clamping Voltage: 65 Volts
- Data Line Impedance: 100 Ohms (balanced)
- Pairs: 1: Pins 1 and 2, 2: Pins 3 and 6, 3: Pins 4 and 5, 4: Pins 7 and 8
- Enclosure Material: Cast Aluminum
- Ground Lug: 12 AWG Max.
- Operating Temperature: -40°C to +80°C
- Weight: 0.28 lbs (0.13 kg)
- Dimensions: 3.6 x 1.4 x 1.2 inches (91.4 x 35.5 x 38.1 mm)
- RoHS Compliant: Yes
Buy the Buy L-com Shielded Lightning Surge Protector Part Number HGLNCAT6J Online
Secure your Ethernet infrastructure with the L-com HGLN-CAT6J lightning protector, designed for indoor environments. Its cast aluminum housing, shielded RJ45 jacks, and ultra-low capacitance semiconductor arrays provide superior surge and lightning protection, minimizing high-frequency signal distortion. Compatible with PoE devices following 802.3af/at standards, it reduces EMI interference and ensures stable connections. Easy to install with integral mounting feet, this industrial-grade protector safeguards IP cameras, wireless access points, bridges, and Gigabit network equipment, delivering dependable high-speed network protection.
Buy L-com HGLN-CAT6J now and ensure reliable lightning and surge protection for high-speed Ethernet networks and PoE applications.
Frequently Asked Questions
Where can I buy L-COM HGLNCAT6J?
You can click on the BUY or RFQ button to purchase HGLNCAT6J from an authorized L-COM distributor.
How do I troubleshoot issues or seek technical support for part HGLNCAT6J?
You can download the HGLNCAT6J datasheet or visit the L-COM website for support.
Who is the manufacturer of HGLNCAT6J?
L-COM
