L-COM LCAT100109 RF Attenuator
The 2W/9dB RF Fixed Attenuator with SMA connectors from INFINITG offers reliable signal attenuation for RF applications up to 3 GHz. Featuring stainless steel body construction, it provides excellent durability and thermal stability. Rated for a maximum power of 2 Watts CW, it reduces signal levels precisely for instrumentation, RF testing, and production systems. Its compact design measures approximately 0.86 inches in length and 0.31 inches in diameter, making it suitable for tight spaces. This device ensures minimal VSWR of 1.15:1, maintaining signal integrity in demanding environments.
L-COM LCAT100109 RF Attenuator Specifications:
- Frequency Range: DC to 3 GHz
- Impedance: 50 Ohms
- Attenuation: 9 ± 0.5 dB
- VSWR: < 1.15:1
- Peak Power: 500 Watts with pulse, 2 Watts CW
- Connector: SMA Male to SMA Female
- Mechanical Size: Length 0.8582 in [21.8 mm], Diameter 0.312 in [7.92 mm]
- Material: Stainless Steel Body, Brass contacts with Gold plating
- Operating Temperature: -55°C to +125°C
- Body Material: Stainless Steel
- Ingress Protection: RoHS compliant
- Temperature Stability: Up to +125°C
Buy the INFINITG LCAT1001-09 – Reliable RF Attenuator for Industrial Applications
Enhance your RF testing and measurement setups with the INFINITG RF Attenuator, rated at 2 Watts and delivering 9 dB attenuation. Designed with stainless steel for durability, it operates up to 3 GHz and features SMA connectors for easy integration. Use it to protect sensitive equipment, match impedances, or extend power meter range. Its compact size, high power handling, and minimal VSWR make it ideal for instrumentation, production systems, and precision RF measurements. Reliable, precise, and easy to install—order online today for seamless performance in demanding environments.
Buy INFINITG LCAT1001-09 now and experience unmatched reliability and performance in RF signal attenuation up to 3 GHz for industrial systems.
