Littelfuse 0451002MRL Fast-Acting Surface Mount Fuse
The Littelfuse Nano[2] SMF Fuse (0451002.MRL) is a compact surface mount fuse ideal for secondary-side over-current protection in a variety of applications. Its wire-in-air design and small size make it suitable for PCB integration using surface mount technology. Key features include fast-acting performance, low-temperature derating, RoHS compliance, halogen-free construction, a wide operating temperature range, and current ratings from 62mA to 15A. Common applications include notebook PCs, telecom systems, LCD/PDP TVs, wireless basestations, and power supplies.
Littelfuse 0451002MRL Fast-Acting Surface Mount Fuse Specifications:
- Agency Approvals: E10480 (6.3A - 15A), LR29862 (62mA - 15A), PS NBK030205-E10480B (1A - 5A), E NBK101105-E184655 (6.3A - 10A), E10480 (62mA - 5A)
- Ampere Rating: 62mA - 15A
- Opening Time: 1/16 –15 (4 hours, Minimum), 1/16 –10 (5 sec., Maximum)
- Interrupting Rating: 5.5000 A @ 125VAC/VDC
- Resistance: 0.00019 Ohms (at 62mA)
- Body Material: Ceramic
- Termination Material: Gold-Plated Caps / Sn-dipped Silver Plated
- Operating Temperature: -55°C to 125°C
- Moisture Sensitivity Level: Level 1, J-STD-020C
- Insulation Resistance: 10,000 ohms minimum
- Thermal Shock: MIL-STD-202, Method 302, Test Condition A
- Mechanical Shock: 100G’s pk amplitude, sawtooth wave 6ms duration
- Vibration: 0.03” amplitude, 10-55 Hz
- Salt Spray: MIL-STD-202, Method 101, Test Condition B (48hrs)
