MAXIM INTEGRATED / ANALOG DEVICES MAX3480EAEPI RS-485/RS-422 Transceiver
The MAX3480EA is an electrically isolated RS-485/RS-422 transceiver that provides high-speed data communication with galvanic isolation up to 1260VRMS. Powered by a single +3.3V supply, it features ESD protection of +15kV for I/O pins, low EMI through reduced slew rates, and integrated optocouplers, transformers, and transceivers in a compact 28-pin PDIP package. Suitable for industrial control, building automation, and EMI-sensitive applications, it ensures reliable, error-free data transmission at up to 2.5Mbps with robust short-circuit and thermal protection.
MAXIM INTEGRATED / ANALOG DEVICES MAX3480EAEPI RS-485/RS-422 Transceiver Specifications:
- Isolation Voltage: 1260 VRMS (1 min)
- ESD Protection: +15kV on I/O pins
- Supply Voltage: +3.3V
- Communication Rate: Up to 2.5 Mbps
- Package: 28-pin PDIP
- Driver Slew Rate: Not limited (MAX3480EA), Reduced slew rate (MAX3480EB)
- Thermal Shutdown: Yes
- Short-circuit Current Limiting: Yes
- Maximum Power Dissipation: 727 mW at 70°C
- Operating Temperature Range: 0°C to +70°C (MAX3480EACPI), -40°C to +85°C (MAX3480EAEPI)
- Transceiver Type: Differential RS-485/RS-422
- Compliance: Meets RS-485/RS-422 standards
- Pin Count: 28
- Optocouplers and transformer included in package
- Power consumption: Low current operation
Buy the Maxim Series MAX3480EAE: RS-485/RS-422 Isolated Data Interface: MAX3480EAEPI
Purchase the Maxim Series MAX3480EAEPI today for your industrial communication projects. This high-speed, isolated RS-485/RS-422 transceiver provides robust galvanic isolation up to 1260VRMS, protecting against high-voltage spikes and ESD events of +15kV. Powered by a single 3.3V supply, it supports data rates up to 2.5Mbps with integrated optocouplers, transformers, and comprehensive thermal and short-circuit protection. Ideal for industrial control, building automation, and EMI-sensitive environments, this compact 28-pin PDIP device ensures reliable, error-free communication in harsh conditions.
Order your Maxim Series MAX3480EAEPI isolated RS-485/RS-422 transceiver today and ensure your industrial communication systems operate with maximum reliability and protection.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX3480EAEPI?
You can click on the BUY or RFQ button to purchase MAX3480EAEPI from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX3480EAEPI?
You can download the MAX3480EAEPI datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX3480EAEPI?
MAXIM INTEGRATED / ANALOG DEVICES
